English - 23
SETTING UP
HOW TO ADJUST THE DOOR GAP
If the gap between the left and right fridge
compartment doors is not even.
• You can adjust the gap by
turning the bolt at the top
right of the cold storage
compartment door.
• Do not turn the bolt too far.
You can break it.
1. With the doors closed, remove the 6 screws
holding the top cover using a Phillips
screwdriver, and then lift it o together with the
connected cables.
2. Turn the bolt with a 4mm
hexagonal L-wrench to
adjust the gap.
(Not provided)
3. Turn the bolt clockwise to ( ) widen the
gap. Turn the bolt counter clockwise ( ) to
narrow the gap.
INSTALLING THE WATER
DISPENSER LINE
A water dispenser with a fi lter is one of the helpful
features on your new refrigerator.
To help promote better health, the water fi lter
removes unwanted particles from your water.
However, it does not sterilize or destroy
microorganisms.
You may need to purchase a water purifying
system to do that.
The water line also connects to the ice maker.
For the ice maker to operate properly, water
pressure of 138~862kPa (1.4~8.8kgf/cm³) is
required.
If the refrigerator is installed in an area with low
water pressure (below 138kPa), you can install a
booster pump to compensate for the low pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator is
properly fi lled.
To do this, press the water dispenser lever until the
water runs from the water outlet.
• Water line installation kits are available at
extra cost from your dealer.
We recommend using a water line
installation kit that contains copper
tubing and ¼” compression nut.
• New hose-sets supplied with the appliance are
to be used and that old hose-sets should not
be reused.
