10 _ Removal and Reassembly
3-2. STANDARD DISASSEMBLY DRAWINGS
To avoid risk of electrical shock, personal injury or death, disconnect the power to the Clothes Dryer.
► Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.
Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.
Part Figure Description
Top Cover Removal
1. DisconnectPowerSupplytoUnit.
2. Remove2screwsTop-Cover.
3. SlideTopCovertowardstherearandliftfromthe
unit.
 Scratchandimpacttotopcoverprohibited.
Main PCB Removal
1. Disconnectthepowersupplyandtotheunit.
2. RemovetheTopCover.
3. Remove3screwsfromtheframe+plate.
4. RemovetheWireholder.
5. RemovetheHousings.
 Shakingtheheaterterminalsidewaystopullit
outisprohibited.
6. Remove1screwfromtheHolderPCB.
