Samsung DVM Chiller - Closed Loop Expansion Tank

33
Chiller System Components
Water Side System Components – Field Supplied
1
Closed loop expansion tank
▪ Expansion tank must be installed on the inlet side of the circulating
water pump above the highest point in the system
▪ Expansion tank sizing: 5% of the total amount of circulating water
in the system
Expansion tank example only
