DVM Chiller Introduction
6
The DVM Chiller is an air to water heat pump
▪ Chill water temperature range: 41°F to 77°F
▪ Chill water temp down to 14°F with antifreeze
▪ Hot water temperature range: 77°F to 131°F
▪ Chiller ambient temperature operating range:
▪ Cooling: 5°F to 118°F
▪ Heating: -13°F to 109°F
▪ 10 ton and 15 ton nominal capacity models
▪ 208/230vac 3Ø and 460vac 3Ø models
▪ Modular combinations from 20 to 240 nominal tons
▪ Up to 16 units can be combined in one control group
▪ Optional DMS 2.5 or Touch Central Controllers enable
control of 3
rd
party air handlers
▪ No field installed refrigerant piping
DVM Chiller Overview
Model AG010 AG015
Water flow Range 16 ~ 48 gpm 17 ~ 68 gpm
