DVM Chiller Introduction
8
DVM Chiller Operation Patterns – System Design
Chiller system hierarchy overview
▪ Unit – One DVM Chiller unit (10 or 15 ton)
▪ Module – 1 to 8 units connected together (required configuration)
1 Unit module
2 Unit module
Unit 0 Unit 1
4 Unit module
Unit 0 Unit 1 Unit 2 Unit 3
8 Unit module
Unit 0 Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Unit 6 Unit 7
