2. Specifications
Premium Compact
Type
DVM S DVM S DVM S
Model Name
AM680KXVGGH1EU AM700KXVGGH1EU AM720KXVGGH1EU
Outdoor unit module 1
AM160KXVGGH/EU AM180KXVGGH/EU AM200KXVGGH/EU
Outdoor unit module 2
AM220KXVGGH/EU AM220KXVGGH/EU AM220KXVGGH/EU
Outdoor unit module 3
AM300KXVAGH/EU AM300KXVAGH/EU AM300KXVAGH/EU
Outdoor unit module 4
- - -
Power Supply Ø, #, V, Hz
3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode -
HEAT PUMP HEAT PUMP HEAT PUMP
Perfor-
mance
HP HP
68 70 72
Capacity (Nominal)
Cooling
kW
190.6 196.0 201.6
Btu/h
650,400 668,800 687,900
Heating
kW
214.2 220.5 226.8
Btu/h
730,900 752,400 773,900
Maximum number of connectable indoor units EA
64 64 64
Total capacity of the connected Indoor Units Min. kW
95.3 98.0 100.8
Total capacity of the connected Indoor Units Max. kW
24 7. 8 254.8 262.1
Power
Power Input (Nominal)
Cooling kW
49.37 49.13 50.95
Heating kW
47. 2 0 46.97 49.20
Current Input (Nominal)
Cooling A
79.20 78.80 81.70
Heating A
75.60 75.30 78.90
Current
Minimum Ssc
MVA
30.6 32.2 31.5
MCA A
149.6 156.8 159.6
MFA A
175 175 175
Efficiency
EER (Nominal) Cooling W/W
3.86 3.99 3.96
COP (Nominal)
Heating
W/W
4.54 4.69 4.61
ESEER W/W
6.75 6.74 6.63
Casing Material
Body -
EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -
EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat
Exchanger
Type -
Fin & Tube Fin & Tube Fin & Tube
Material
Fin -
Al Al Al
Tube -
Cu Cu Cu
Fin Treatment -
Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name -
DS4GJ5080FVA x 3 +
DSGB066FAVB x 2
DS-GB066FAVB x 4 +
DS4GJ5080FVA x 2
DS-GB066FAVB x 4 +
DS4GJ5080FVA x 2
Output kW x n
(7.81 x 1) x 1 + (6.39 x 2) x 1 +
(7.81 x 2) x 1
(6.39 x 2) x 2 + (7.81 x 2) x 1 (6.39 x 2) x 2 + (7.81 x 2) x 1
Oil
Type -
PVE PVE PVE
Initial charge
cc x n
(1,400 x 1) x 1 +
(1,100 x 2) x 1 + (1,400 x 2) x 1
(1,100 x 2) x 2 +
(1,400 x 2) x 1
(1,100 x 2) x 2 +
(1,400 x 2) x 1
Fan
Type -
Propeller Propeller Propeller
Discharge direction -
Top Top Top
Quantity EA
6 6 6
Air Flow Rate
m
5
/min
255 x 1 + 290 x 1 + 340 x 1 290 x 2 + 340 x 1 290 x 2 + 340 x 1
l/s
4,250 x 1 + 4,833 x 1 + 5,667 x 1 4,833 x 2 + 5,667 x 1 4,833 x 2 + 5,667 x 1
External Static Pressure Max.
mmAq
8 8 8
Pa
78.45 78.45 78.45
Fan Motor
Type -
BLDC Motor BLDC Motor BLDC Motor
Output W x n
(620 x 2) x 3 (620 x 2) x 3 (620 x 2) x 3
Piping
Connections
Liquid Pipe
Type
Braze connection Braze connection Braze connection
Φ, mm (inch)
22.22 (7/8) 22.22 (7/8) 22.22 (7/8)
Gas Pipe
Type
Braze connection Braze connection Braze connection
Φ, mm (inch)
53.98 (2-1/8) 53.98 (2-1/8) 53.98 (2-1/8)
High pressure Gas Pipe(HR Only)
Type
- - -
Φ, mm (inch)
- - -
Heat Insulation -
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.]
m
200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU) Max. m
90 90 90
Total piping length (System) Max. m
1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m
110 110 110
Level difference (IDU in highest position) Max. m
110 110 110
Level difference (IDU-IDU) Max. m
50 50 50
