2. Specifications
Premium Compact
Type
DVM S DVM S DVM S
Model Name
AM860KXVGGH1EU AM880KXVGGH1EU AM900KXVGGH1EU
Outdoor unit module 1
AM260KXVGGH/EU AM280KXVGGH/EU AM300KXVAGH/EU
Outdoor unit module 2
AM300KXVAGH/EU AM300KXVAGH/EU AM300KXVAGH/EU
Outdoor unit module 3
AM300KXVAGH/EU AM300KXVAGH/EU AM300KXVAGH/EU
Outdoor unit module 4
- - -
Power Supply Ø, #, V, Hz
3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode -
HEAT PUMP HEAT PUMP HEAT PUMP
Perfor-
mance
HP HP
86 88 90
Capacity (Nominal)
Cooling
kW
240.8 246.6 252.0
Btu/h
821,600 841,400 859,900
Heating
kW
270.9 2 7 7. 2 283.5
Btu/h
924,300 945,800 967,300
Maximum number of connectable indoor units EA
64 64 64
Total capacity of the connected Indoor Units Min. kW
120.4 123.3 126.0
Total capacity of the connected Indoor Units Max. kW
313.0 320.6 327.6
Power
Power Input (Nominal)
Cooling kW
62.73 65.05 68.10
Heating kW
58.24 59.95 61.77
Current Input (Nominal)
Cooling A
100.60 104.30 109.20
Heating A
93.40 96.10 99.00
Current
Minimum Ssc
MVA
41.8 43.2 44.4
MCA A
206 213 219
MFA A
250 250 250
Efficiency
EER (Nominal) Cooling W/W
3.84 3.79 3.70
COP (Nominal)
Heating
W/W
4.65 4.62 4.59
ESEER W/W
6.81 6.72 6.65
Casing Material
Body -
EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -
EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat
Exchanger
Type -
Fin & Tube Fin & Tube Fin & Tube
Material
Fin -
Al Al Al
Tube -
Cu Cu Cu
Fin Treatment -
Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name -
DS4GJ5080FVA x 6 DS4GJ5080FVA x 6 DS4GJ5080FVA x 6
Output kW x n
(7.81 x 2) x 3 (7.81 x 2) x 3 (7.81 x 2) x 3
Oil
Type -
PVE PVE PVE
Initial charge
cc x n
(1,400 x 2) x 3 (1,400 x 2) x 3 (1,400 x 2) x 3
Fan
Type -
Propeller Propeller Propeller
Discharge direction -
Top Top Top
Quantity EA
6 6 6
Air Flow Rate
m
5
/min
340 x 3 340 x 3 340 x 3
l/s
5,667 x 3 5,667 x 3 5,667 x 3
External Static Pressure Max.
mmAq
8 8 8
Pa
78.45 78.45 78.45
Fan Motor
Type -
BLDC Motor BLDC Motor BLDC Motor
Output W x n
(620 x 2) x 3 (620 x 2) x 3 (620 x 2) x 3
Piping
Connections
Liquid Pipe
Type
Braze connection Braze connection Braze connection
Φ, mm (inch)
22.22 (7/8) 22.22 (7/8) 22.22 (7/8)
Gas Pipe
Type
Braze connection Braze connection Braze connection
Φ, mm (inch)
53.98 (2-1/8) 53.98 (2-1/8) 53.98 (2-1/8)
High pressure Gas Pipe(HR Only)
Type
- - -
Φ, mm (inch)
- - -
Heat Insulation -
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.]
m
200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU) Max. m
90 90 90
Total piping length (System) Max. m
1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m
110 110 110
Level difference (IDU in highest position) Max. m
110 110 110
Level difference (IDU-IDU) Max. m
50 50 50
