2. Specifications
Premium Energy Efficiency
Type DVM S DVM S DVM S
Model Name AM220KXVGGH2EU AM240KXVGGH2EU AM260KXVGGH2EU
Outdoor unit module 1 AM100JXVHGH/EU AM120JXVHGH/EU AM080JXVHGH/EU
Outdoor unit module 2 AM120JXVHGH/EU AM120JXVHGH/EU AM180KXVGGH/EU
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 22 24 26
Capacity (Nominal)
Cooling
kW 61.6 6 7. 2 72.8
Btu/h 210,200 229,300 248,400
Heating
kW 69.3 75.6 81.9
Btu/h 236,500 258,000 279,500
Maximum number of connectable indoor units EA 40 43 47
Total capacity of the connected Indoor Units
Min.
kW 30.8 33.6 36.4
Total capacity of the connected Indoor Units
Max.
kW 80.1 87.4 94.6
Power
Power Input (Nominal)
Cooling
kW 13.79 15.14 15.27
Heating
kW 13.45 15.12 15.11
Current Input (Nominal)
Cooling
A 22.10 24.20 24.50
Heating
A 21.50 24.20 24.30
Current
Minimum Ssc
MVA 9.8 10.6 11.9
MCA
A 46.1 50 57. 2
MFA
A 63 63 63
Efficiency
EER (Nominal)
Cooling
W/W 4.47 4.44 4.77
COP (Nominal)
Heating
W/W 5.15 5.00 5.42
ESEER W/W 7.32 7. 2 3 7.48
Casing Material
Body
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin
- Al Al Al
Tube
- Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name - DS-GB066FAVBSG x 2 DS-GB066FAVBSG x 2
DS-GB066FAVB x 2 +
DSGB052FAVBSG x 1
Output kW x n (6.39 x 1) x 2 (6.39 x 1) x 2 (5.18 x 1) x 1 + (6.39 x 2) x 1
Oil
Type
- PVE PVE PVE
Initial charge
cc x n
(1,100 x 1) x 2 (1,100 x 1) x 2 (1,100 x 1) x 1 + (1,100 x 2) x 1
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 2 2 3
Air Flow Rate
m
2
/min 170 x 1 + 220 x 1 220 x 2 170 x 1 + 290 x 1
l/s 2,833 x 1 + 3,667 x 1 3,667 x 2 2,833 x 1 + 4,833 x 1
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n (830 x 1) x 2 (830 x 1) x 2 (830 x 1) x 1 + (620 x 2) x 1
Piping Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
15.88 (5/8) 15.88 (5/8) 19.05 (3/4)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
28.58 (1-1/8) 34.92 (1-3/8) 34.92 (1-3/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.]
m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max.
m 90 90 90
Total piping length (System)
Max.
m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max.
m 110 110 110
Level difference (IDU in highest position)
Max.
m 110 110 110
Level difference (IDU-IDU)
Max.
m 50 50 50
