2. Specifications
Premium Energy Efficiency
Type DVM S DVM S DVM S
Model Name AM340KXVGGH2EU AM360KXVGGH2EU AM380KXVGGH2EU
Outdoor unit module 1 AM080JXVHGH/EU AM180KXVGGH/EU AM180KXVGGH/EU
Outdoor unit module 2 AM080JXVHGH/EU AM180KXVGGH/EU AM200KXVGGH/EU
Outdoor unit module 3 AM180KXVGGH/EU - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 34 36 38
Capacity (Nominal)
Cooling
kW 95.2 100.8 106.4
Btu/h 324,800 343,900 363,100
Heating
kW 1 07.1 113.4 119.7
Btu/h 365,400 386,900 408,400
Maximum number of connectable indoor units EA 61 64 64
Total capacity of the connected Indoor Units
Min.
kW 47. 6 50.4 53.2
Total capacity of the connected Indoor Units
Max.
kW 123.8 131.0 138.3
Power
Power Input (Nominal)
Cooling
kW 19.86 21.36 23.18
Heating
kW 19.70 21.04 23.27
Current Input (Nominal)
Cooling
A 31.90 34.20 37.10
Heating
A 31.70 33.80 3 7.40
Current
Minimum Ssc
MVA 15 17.6 16.9
MCA
A 75.2 78.4 81.2
MFA
A 90 90 90
Efficiency
EER (Nominal)
Cooling
W/W 4.79 4.72 4.59
COP (Nominal)
Heating
W/W 5.44 5.39 5.14
ESEER W/W 7.60 7. 25 7. 0 2
Casing Material
Body
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin
- Al Al Al
Tube
- Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name -
DS-GB066FAVB x 2 +
DSGB052FAVBSG x 2
DS-GB066FAVB x 4 DS-GB066FAVB x 4
Output kW x n
(5.18 x 1) x 2 + (6.39 x 2) x 1 (6.39 x 2) x 2 (6.39 x 2) x 2
Oil
Type
- PVE PVE PVE
Initial charge
cc x n
(1,100 x 1) x 2 + (1,100 x 2) x 1 (1,100 x 2) x 2 (1,100 x 2) x 2
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 4 4 4
Air Flow Rate
m
2
/min 170 x 2 + 290 x 1 290 x 2 290 x 2
l/s 2,833 x 2 + 4,833 x 1 4,833 x 2 4,833 x 2
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n (830 x 1) x 2 + (620 x 2) x 1 (620 x 2) x 2 (620 x 2) x 2
Piping Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
19.05 (3/4) 19.05 (3/4) 19.05 (3/4)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
34.92 (1-3/8) 41.28 (1-5/8) 41.28 (1-5/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.]
m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max.
m 90 90 90
Total piping length (System)
Max.
m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max.
m 110 110 110
Level difference (IDU in highest position)
Max.
m 110 110 110
Level difference (IDU-IDU)
Max.
m 50 50 50
