2. Specifications
Premium Energy Efficiency
Type DVM S DVM S DVM S
Model Name AM760KXVGGH2EU AM780KXVGGH2EU AM800KXVGGH2EU
Outdoor unit module 1 AM180KXVGGH/EU AM180KXVGGH/EU AM180KXVGGH/EU
Outdoor unit module 2 AM180KXVGGH/EU AM200KXVGGH/EU AM180KXVGGH/EU
Outdoor unit module 3 AM200KXVGGH/EU AM200KXVGGH/EU AM180KXVGGH/EU
Outdoor unit module 4 AM200KXVGGH/EU AM200KXVGGH/EU AM260KXVGGH/EU
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 76 78 80
Capacity (Nominal)
Cooling
kW 212.8 218.4 224.0
Btu/h 726,100 745,200 764,300
Heating
kW 239.4 245.7 252.0
Btu/h 816,900 838,400 859,900
Maximum number of connectable indoor units EA 64 64 64
Total capacity of the connected Indoor Units
Min.
kW 106.4 109.2 112.0
Total capacity of the connected Indoor Units
Max.
kW 276.6 283.9 291.2
Power
Power Input (Nominal)
Cooling
kW 46.36 48.18 49.37
Heating
kW 46.54 48.77 48.62
Current Input (Nominal)
Cooling
A 74.20 7 7.1 0 79.10
Heating
A 74.80 78.40 78.10
Current
Minimum Ssc
MVA 33.8 33.1 38.6
MCA
A 162.4 165.2 1 7 7. 6
MFA
A 200 200 200
Efficiency
EER (Nominal)
Cooling
W/W 4.59 4.53 4.54
COP (Nominal)
Heating
W/W 5.14 5.04 5.18
ESEER W/W 7.02 6.92 7. 2 2
Casing Material
Body
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base
- EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin
- Al Al Al
Tube
- Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name - DS-GB066FAVB x 8 DS-GB066FAVB x 8
DS-GB066FAVB x 6 +
DS4GJ5080FVA x 2
Output kW x n
(6.39 x 2) x 4 (6.39 x 2) x 4 (6.39 x 2) x 3 + (7.81 x 2) x 1
Oil
Type
- PVE PVE PVE
Initial charge
cc x n
(1,100 x 2) x 4 (1,100 x 2) x 4 (1,100 x 2) x 3 + (1,400 x 2) x 1
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 8 8 8
Air Flow Rate
m
2
/min 290 x 4 290 x 4 290 x 3 + 340 x 1
l/s
4,833 x 4 4,833 x 4 4,833 x 3 + 5,667 x 1
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n
(620 x 2) x 4 (620 x 2) x 4 (620 x 2) x 4
Piping Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
22.22 (7/8) 22.22 (7/8) 22.22 (7/8)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
53.98 (2-1/8) 53.98 (2-1/8) 53.98 (2-1/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.]
m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max.
m 90 90 90
Total piping length (System)
Max.
m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max.
m 110 110 110
Level difference (IDU in highest position)
Max.
m 110 110 110
Level difference (IDU-IDU)
Max.
m 50 50 50
