67
2. Specifications
Standard
Type DVM S DVM S DVM S
Model Name
AM080JXVAGH/EU AM100JXVAGH/EU AM120JXVAGH/EU
Outdoor unit module 1 - - -
Outdoor unit module 2 - - -
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 8 10 12
Capacity (Nominal)
Cooling
kW 22.4 28.0 33.6
Btu/h 76,400 95,500 114,600
Heating
kW 25.2 31.5 37.8
Btu/h 86,000 107,500 129,000
Maximum number of connectable indoor units EA 14 18 21
Total capacity of the connected Indoor Units
Min. kW 11.2 14.0 16.8
Total capacity of the connected Indoor Units
Max. kW 29.1 36.4 43.7
Power
Power Input (Nominal)
Cooling kW 5.00 6.85 8.16
Heating kW 5.10 6.65 8.03
Current Input (Nominal)
Cooling A 8.00 11.00 13.10
Heating A 8.20 10.70 12.90
Current
Minimum Ssc
MVA 3.1 4.5 5.3
MCA A 18.0 21.1 25.0
MFA A 25 32 32
Efficiency
EER (Nominal) Cooling W/W 4.48 4.09 4.12
COP (Nominal) Heating W/W 4.94 4.74 4.71
ESEER W/W 7.85 7. 25 7.03
Casing Material
Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name - DS-GA046FAVADO x 1 DS-GB066FAVB x 1 DS-GB066FAVB x 1
Output kW x n 4.39 x 1 6.39 x 1 6.39 x 1
Oil
Type - PVE PVE PVE
Initial charge
cc x n 900 x 1 1,100 x 1 1,100 x 1
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 1 1 1
Air Flow Rate
m
2
/min 170 170 220
l/s 2,833 2,833 3,667
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n 830 x 1 830 x 1 830 x 1
Piping Connec-
tions
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
9.52 (3/8) 9.52 (3/8) 12.70 (1/2)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
19.05 (3/4) 22.22 (7/8) 28.58 (1-1/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.] m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max. m 90 90 90
Total piping length (System)
Max. m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m 110 110 110
Level difference (IDU in highest position)
Max. m 110 110 110
Level difference (IDU-IDU)
Max. m 50 50 50
