2. Specifications
Standard
Type DVM S DVM S DVM S
Model Name
AM200KXVAGH/EU AM220KXVAGH/EU AM240KXVAGH/EU
Outdoor unit module 1 - - -
Outdoor unit module 2 - - -
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 20 22 24
Capacity (Nominal)
Cooling
kW 56.0 61.6 6 7. 2
Btu/h 191,100 210,200 229,300
Heating
kW 63.0 69.3 75.6
Btu/h 215,000 236,500 258,000
Maximum number of connectable indoor units EA 36 40 43
Total capacity of the connected Indoor Units
Min. kW 28.0 30.8 33.6
Total capacity of the connected Indoor Units
Max. kW 72.8 80.1 8 7. 4
Power
Power Input (Nominal)
Cooling kW 14.18 17.35 17.10
Heating kW 13.91 16.70 17.42
Current Input (Nominal)
Cooling A 22.70 27.80 27.40
Heating A 22.30 26.80 27.90
Current
Minimum Ssc
MVA 8.1 8.6 12.5
MCA A 42.0 44.6 55.0
MFA A 63 63 63
Efficiency
EER (Nominal) Cooling W/W 3.95 3.55 3.93
COP (Nominal) Heating W/W 4.53 4.15 4.34
ESEER W/W 6.56 6.25 7.0 6
Casing Material
Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name - DS-GB052FAVB x 2 DS-GB066FAVB x 2 DS-GB066FAVB x 2
Output kW x n 6.39 x 2 6.39 x 2 6.39 x 2
Oil
Type - PVE PVE PVE
Initial charge
cc x n 1,100 x 2 1,100 x 2 1,100 x 2
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 2 2 2
Air Flow Rate
m
2
/min 290 290 340
l/s 4,833 4,833 5,667
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n 620 x 2 620 x 2 620 x 2
Piping Connec-
tions
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
28.58 (1-1/8) 28.58 (1-1/8) 34.92 (1-3/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.] m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max. m 90 90 90
Total piping length (System)
Max. m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m 110 110 110
Level difference (IDU in highest position)
Max. m 110 110 110
Level difference (IDU-IDU)
Max. m 50 50 50
