2. Specifications
Standard
Type DVM S DVM S DVM S
Model Name
AM380KXVAGH/EU AM400KXVAGH/EU AM420KXVAGH/EU
Outdoor unit module 1 AM160KXVAGH/EU AM180KXVAGH/EU AM200KXVAGH/EU
Outdoor unit module 2 AM220KXVAGH/EU AM220KXVAGH/EU AM220KXVAGH/EU
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 38 40 42
Capacity (Nominal)
Cooling
kW 106.6 112.0 117.6
Btu/h 363,700 382,200 401,300
Heating
kW 119.7 126.0 132.3
Btu/h 408,400 429,900 451,400
Maximum number of connectable indoor units EA 64 64 64
Total capacity of the connected Indoor Units
Min. kW 53.3 56.0 58.8
Total capacity of the connected Indoor Units
Max. kW 138.6 145.6 152.9
Power
Power Input (Nominal)
Cooling kW 29.45 29.95 31.53
Heating kW 28.31 28.61 30.61
Current Input (Nominal)
Cooling A 47. 2 0 48.00 50.50
Heating A 45.40 45.90 49.10
Current
Minimum Ssc
MVA 15.8 17.4 16.7
MCA A 76.6 83.8 86.6
MFA A 90 100 100
Efficiency
EER (Nominal) Cooling W/W 3.62 3.74 3.73
COP (Nominal) Heating W/W 4.23 4.40 4.32
ESEER W/W 6.49 6.41 6.40
Casing Material
Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name -
DS4GJ5080FVA x 1 +
DSGB066FAVB x 2
DS4GJ5080FVA x 1 +
DSGB066FAVB x 2
DS-GB052FAVBx2 +
DSGB066FAVBx2
Output kW x n (7.81 x 1) x 1 + (6.39 x 2) x 1 (7.81 x 1) x 1 + (6.39 x 2) x 1 (6.39 x 2) x 2
Oil
Type - PVE PVE PVE
Initial charge
cc x n
(1,400 x 1) x 1 + (1,100 x 2) x 1 (1,400 x 1) x 1 + (1,100 x 2) x 1 (1,100 x 2) x 2
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 4 4 4
Air Flow Rate
m
2
/min 255 x 1 + 290 x 1 290 x 2 290 x 2
l/s 4,250 x 1 + 4,833 x 1 4,833 x 2 4,833 x 2
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n (620 x 2) x 2 (620 x 2) x 2 (620 x 2) x 2
Piping Connec-
tions
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
19.05 (3/4) 19.05 (3/4) 19.05 (3/4)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
41.28 (1-5/8) 41.28 (1-5/8) 41.28 (1-5/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.] m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max. m 90 90 90
Total piping length (System)
Max. m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m 110 110 110
Level difference (IDU in highest position)
Max. m 110 110 110
Level difference (IDU-IDU)
Max. m 50 50 50
