2. Specifications
Standard
Type DVM S DVM S DVM S
Model Name
AM440KXVAGH/EU AM460KXVAGH/EU AM480KXVAGH/EU
Outdoor unit module 1 AM220KXVAGH/EU AM160KXVAGH/EU AM180KXVAGH/EU
Outdoor unit module 2 AM220KXVAGH/EU AM300KXVAGH/EU AM300KXVAGH/EU
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 44 46 48
Capacity (Nominal)
Cooling
kW 123.2 129.0 134.4
Btu/h 420,400 440,200 458,600
Heating
kW 138.6 144.9 151.2
Btu/h 472,900 494,400 515,900
Maximum number of connectable indoor units EA 64 64 64
Total capacity of the connected Indoor Units
Min. kW 61.6 64.5 6 7. 2
Total capacity of the connected Indoor Units
Max. kW 160.2 167.7 174.7
Power
Power Input (Nominal)
Cooling kW 34.70 34.80 35.30
Heating kW 33.40 32.20 32.50
Current Input (Nominal)
Cooling A 55.60 55.80 56.60
Heating A 53.60 51.60 52.10
Current
Minimum Ssc
MVA 17. 2 22 23.6
MCA A 89.2 105 112.2
MFA A 100 125 125
Efficiency
EER (Nominal) Cooling W/W 3.55 3.71 3.81
COP (Nominal) Heating W/W 4.15 4.50 4.65
ESEER W/W 6.25 6.71 6.64
Casing Material
Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name - DS-GB066FAVBx4 DS4GJ5080FVA x 3 DS4GJ5080FVA x 3
Output kW x n (6.39 x 2) x 2 (7.81 x 1) x 1 + (7.81 x 2) x 1 (7.81 x 1) x 1 + (7.81 x 2) x 1
Oil
Type - PVE PVE PVE
Initial charge
cc x n
(1,100 x 2) x 2 (1,400 x 1) x 1 + (1,400 x 2) x 1 (1,400 x 1) x 1 + (1,400 x 2) x 1
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 4 4 4
Air Flow Rate
m
2
/min 290 x 2 255 x 1 + 340 x 1 290 x 1 + 340 x 1
l/s 4,833 x 2 4,250 x 1 + 5,667 x 1 4,833 x 1 + 5,667 x 1
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n (620 x 2) x 2 (620 x 2) x 2 (620 x 2) x 2
Piping Connec-
tions
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
19.05 (3/4) 19.05 (3/4) 19.05 (3/4)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
41.28 (1-5/8) 41.28 (1-5/8) 41.28 (1-5/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.] m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max. m 90 90 90
Total piping length (System)
Max. m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m 110 110 110
Level difference (IDU in highest position)
Max. m 110 110 110
Level difference (IDU-IDU)
Max. m 50 50 50
