2. Specifications
Standard
Type DVM S DVM S DVM S
Model Name
AM500KXVAGH/EU AM520KXVAGH/EU AM540KXVAGH/EU
Outdoor unit module 1 AM200KXVAGH/EU AM220KXVAGH/EU AM240KXVAGH/EU
Outdoor unit module 2 AM300KXVAGH/EU AM300KXVAGH/EU AM300KXVAGH/EU
Outdoor unit module 3 - - -
Outdoor unit module 4 - - -
Power Supply Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance
HP HP 50 52 54
Capacity (Nominal)
Cooling
kW 140.0 145.6 151.2
Btu/h 477,700 496,800 515,900
Heating
kW 1 5 7. 5 163.8 170.1
Btu/h 537,400 558,900 580,400
Maximum number of connectable indoor units EA 64 64 64
Total capacity of the connected Indoor Units
Min. kW 70.0 72.8 75.6
Total capacity of the connected Indoor Units
Max. kW 182.0 189.3 196.6
Power
Power Input (Nominal)
Cooling kW 36.88 40.05 39.80
Heating kW 34.50 3 7. 29 38.01
Current Input (Nominal)
Cooling A 59.10 64.20 63.80
Heating A 55.30 59.80 60.90
Current
Minimum Ssc
MVA 22.9 23.4 2 7. 3
MCA A 115 117.6 128
MFA A 150 150 150
Efficiency
EER (Nominal) Cooling W/W 3.80 3.64 3.80
COP (Nominal) Heating W/W 4.57 4.39 4.48
ESEER W/W 6.61 6.48 6.83
Casing Material
Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Heat Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Anti-corrosion Anti-corrosion Anti-corrosion
Compressor
Model Name -
DS-GB052FAVB x 2 +
DS4GJ5080FVA x 2
DS-GB066FAVB x 2 +
DS4GJ5080FVA x 2
DS-GB066FAVB x 2 +
DS4GJ5080FVA x 2
Output kW x n (6.39 x 2) x 1 + (7.81 x 2) x 1 (6.39 x 2) x 1 + (7.81 x 2) x 1 (6.39 x 2) x 1 + (7.81 x 2) x 1
Oil
Type - PVE PVE PVE
Initial charge
cc x n
(1,100 x 2) x 1 + (1,400 x 2) x 1 (1,100 x 2) x 1 + (1,400 x 2) x 1 (1,100 x 2) x 1 + (1,400 x 2) x 1
Fan
Type - Propeller Propeller Propeller
Discharge direction - Top Top Top
Quantity EA 4 4 4
Air Flow Rate
m
2
/min 290 x 1 + 340 x 1 290 x 1 + 340 x 1 340 x 2
l/s 4,833 x 1 + 5,667 x 1 4,833 x 1 + 5,667 x 1 5,667 x 2
External Static Pressure
Max.
mmAq 8 8 8
Pa 78.45 78.45 78.45
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n (620 x 2) x 2 (620 x 2) x 2 (620 x 2) x 2
Piping Connec-
tions
Liquid Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
19.05 (3/4) 19.05 (3/4) 19.05 (3/4)
Gas Pipe
Type Braze connection Braze connection Braze connection
Φ, mm (inch)
41.28 (1-5/8) 41.28 (1-5/8) 41.28 (1-5/8)
High pressure Gas Pipe(HR Only)
Type - - -
Φ, mm (inch)
- - -
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length (ODU-IDU)
Max. [Equiv.] m 200 [220] 200 [220] 200 [220]
Piping length (1st Branch-IDU)
Max. m 90 90 90
Total piping length (System)
Max. m 1,000 1,000 1,000
Level difference (ODU in highest position)
Max. m 110 110 110
Level difference (IDU in highest position)
Max. m 110 110 110
Level difference (IDU-IDU)
Max. m 50 50 50
