3. Electrical Characteristics
Premium Compact
NOTE
• MCA : Mimium circuit amperes
• MFA : Maximum fuse amperes
• TOCA : Total over current amperes
• FLA : Full load amperes
• MSC : Maximum starting current.
DVM S uses inverter compress. Starting current is always ≤ TOCA.
Capacity
Model
Power Supply Voltage Range Nominal Running
Current [A]
Current [A] ODU Fan Motor
Hz Voltage
Min.
(-10%)
Max.
(+10%)HP kW Cooling Heating MCA MFA TOCA kW FLA [A]
8 22.40 AM080JXVHGH/EU 50 380-415 342 456 7. 40 7.40 18.0 25.0 19.8 0.83 2.4
10 28.00 AM100JXVHGH/EU 50 380-415 342 456 10.00 9.40 21.1 32.0 23.2 0.83 2.4
12 33.60 AM120JXVHGH/EU 50 380-415 342 456 12.10 12.10 25.0 32.0 27.5 0.83 2.4
14 39.20 AM140KXVGGH/EU 50 380-415 342 456 14.30 15.40 25.0 32.0 27.5 1.24 3.8
16 44.80 AM160KXVGGH/EU 50 380-415 342 456 17.50 17.20 32.0 40.0 35.2 1.24 3.8
18 50.40 AM180KXVGGH/EU 50 380-415 342 456 17.10 16.90 39.2 50.0 43.1 1.24 3.8
20 56.00 AM200KXVGGH/EU 50 380-415 342 456 20.00 20.50 42.0 63.0 46.2 1.24 3.8
22 61.60 AM220KXVGGH/EU 50 380-415 342 456 25.30 25.40 44.6 63.0 49.1 1.24 3.8
24 67.20 AM240KXVGGH/EU 50 380-415 342 456 25.70 24.70 55.0 63.0 60.5 1.24 3.8
26 72.80 AM260KXVGGH/EU 50 380-415 342 456 27.80 27.4 0 60.0 75.0 66.0 1.24 3.8
28 78.40 AM280KXVGGH/EU 50 380-415 342 456 31.50 30.10 67. 0 75.0 73.7 1.24 3.8
30 84.00 AM300KXVAGH/EU 50 380-415 342 456 36.40 33.00 73.0 80.0 80.3 1.24 3.8
32 89.60 AM320KXVGGH1EU 50 380-415 342 456 32.10 32.60 67.0 80.0 73.7 2.07 6.2
34 95.20 AM340KXVGGH1EU 50 380-415 342 456 37. 4 0 37.50 69.6 80.0 76.6 2.07 6.2
36 100.80 AM360KXVGGH1EU 50 380-415 342 456 39.60 40.80 69.6 80.0 76.6 2.48 7.6
38 106.40 AM380KXVGGH1EU 50 380-415 342 456 42.80 42.60 76.6 90.0 84.3 2.48 7.6
40 112.00 AM400KXVGGH1EU 50 380-415 342 456 42.40 42.30 83.8 100.0 92.2 2.48 7.6
42 117.60 AM420KXVGGH1EU 50 380-415 342 456 45.30 45.90 86.6 100.0 95.3 2.48 7. 6
44 123.20 AM440KXVGGH1EU 50 380-415 342 456 50.70 48.40 98.0 125.0 107.8 2.48 7. 6
46 128.80 AM460KXVGGH1EU 50 380-415 342 456 53.90 50.20 105.0 125.0 115.5 2.48 7. 6
48 134.40 AM480KXVGGH1EU 50 380-415 342 456 53.50 49.90 112.2 125.0 123.4 2.48 7.6
50 140.00 AM500KXVGGH1EU 50 380-415 342 456 56.40 53.50 115.0 150.0 126.5 2.48 7. 6
52 145.60 AM520KXVGGH1EU 50 380-415 342 456 61.70 58.40 117.6 150.0 129.4 2.48 7.6
54 151.20 AM540KXVGGH1EU 50 380-415 342 456 62.10 57.70 128.0 150.0 140.8 2.48 7. 6
56 156.80 AM560KXVGGH1EU 50 380-415 342 456 64.20 60.40 133.0 150.0 146.3 2.48 7.6
58 162.40 AM580KXVGGH1EU 50 380-415 342 456 67.90 63.10 140.0 175.0 154.0 2.48 7.6
60 168.00 AM600KXVGGH1EU 50 380-415 342 456 72.80 66.00 146.0 175.0
160.6 2.48 7. 6
62 173.60 AM620KXVGGH1EU 50 380-415 342 456 68.50 65.60 140.0 175.0 154.0 3.31 10.0
64 179.20 AM640KXVGGH1EU 50 380-415 342 456 73.80 70.50 142.6 175.0 156.9 3.31 10.0
66 184.80 AM660KXVGGH1EU 50 380-415 342 456 76.00 73.80 142.6 175.0 156.9 3.72 11.4
68 190.40 AM680KXVGGH1EU 50 380-415 342 456 79.20 75.60 149.6 175.0 164.6 3.72 11.4
70 196.00 AM700KXVGGH1EU 50 380-415 342 456 78.80 75.30 156.8 175.0 172.5 3.72 11.4
72 201.60 AM720KXVGGH1EU 50 380-415 342 456 81.70 78.90 159.6 175.0 175.6 3.72 11.4
74 207.20 AM740KXVGGH1EU 50 380-415 342 456 87.00 83.80 162.2 200.0 178.4 3.72 11.4
76 212.80 AM760KXVGGH1EU 50 380-415 342 456 8 7.4 0 83.10 172.6 200.0 189.9 3.72 11.4
78 218.40 AM780KXVGGH1EU 50 380-415 342 456 89.50 85.80 1 7 7. 6 200.0 195.4 3.72 11.4
80 224.00 AM800KXVGGH1EU 50 380-415 342 456 93.20 88.50 184.6 225.0 203.1 3.72 11.4
82 229.60 AM820KXVGGH1EU 50 380-415 342 456 98.10 91.40 190.6 225.0 209.7 3.72 11.4
84 235.20 AM840KXVGGH1EU 50 380-415 342 456 98.50 90.70 201.0 225.0 221.1 3.72 11.4
86 240.80 AM860KXVGGH1EU 50 380-415 342 456 100.60 93.40 206.0 250.0 226.6 3.72 11.4
88 246.40 AM880KXVGGH1EU 50 380-415 342 456 104.30 96.10 213.0 250.0 234.3 3.72 11.4
90 252.00 AM900KXVGGH1EU 50 380-415 342 456 109.20 99.00 219.0 250.0 240.9 3.72 11.4
