Installation
Installation
English18
3. When both sides of the panel lock
into place, press the top center of the
custom panel to secure it to the top of
the door.
NOTE
• Make sure that the custom panel ts in
the dishwasher properly.
• If the gap between the dishwasher and
the custom panel is below 2 mm, proper
installation is done. For 2 mm or more,
remove the custom panel and try again.
4. Unpack the caps and screws (two for
each) included in the product package.
5. Tighten the screws on either side of the
dishwasher.
NOTE
When tightening the screw on either side,
make sure to check the gap between either
side as the custom door may lean in either
side.
