3-3
3. Disassembly and Assembly
Description Photo Screws
4. Turn the monitor over again to remove the back
cover.
5. Remove the LVDS, LAMP wire and FUNCTION
cable then remove the SHIELD-COVER.
LAMP
WIRE
LVDS
FUNCTION
6. Remove the LCD panel.
7. Remove the four (4) screws shown in the gure.
