5-2
5. Exploded View & Part List
5-1-1. LS23CLZSB/XF - Parts List
Location No. Code No. Description & Specication Q’ty SA/SNA Remark
F001A BN96-13088B ASSY COVER P-FRONT;E2320,ABS,HB,BK23,SIM 1 SA
M0014 BN94-03397A ASSY PCB MAIN-STZ;E2320,STZ 1 SA
M0107 BN63-06316B SHIELD-COVER;PLUM 23,SECC,T0.8,DUAL 1 SNA
M0174 BN44-00323A IP BOARD;PWI2304PC(A),PLUM23,23.6,24"w,0 1 SA
M0215 BN07-00609A LCD-PANEL;LTM230HT01,SSRZTS,6Bit + Hi-FR 1 SA
R001A BN96-13099A ASSY COVER P-REAR;Cobalt E2320, E2320X,H 1 SA
SB01A BN96-12853A ASSY STAND P-BODY;COBALT,HIPS,BK23,ETCH 1 SA
SB04A BN96-12977A ASSY STAND P-BASE;COBALT ,19N,21.5~23,HI 1 SA
BN63-06317A SHIELD-LAMP;PLUM 23'',SPTE,T0.3 1 SNA
