Samsung EX2220 - LS22 CLUSF;XF - Parts List (EX2220 X)

5-3
5. Exploded View & Part List
5-2. LS22CLUSF/XF - Parts List (EX2220X)
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.1 R001A BN90-02667A ASSY COVER REAR;EX2220,BLACK,texture 1 SNA
..2 R001A BN96-12855A ASSY COVER P-REAR;Cobalt 21.5,HIPS,HB,BK 1 SA
...3 W391 6003-000275
SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),S
WR
2 SA
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 SNA
...3 T0060 BN61-05331A SPRING ETC;LAVENDER 23",SK5,T0.5 1 SNA
...3 CIS4 BN61-05332A
HOLDER-STAND;LAVENDER
23",ACETAL,WHITE
1 SNA
...3 M0111 BN63-05625A COVER-STAND;LAVENDER 23W,BK23 1 SNA
...3 R001 BN63-06702A COVER-REAR;Cobalt 21.5,HIPS,HB,BK23,EX22 1 SNA
...3 BN96-13319A ASSY SHIELD P-LAMP;Cobalt 21.5W,SPTE,T0. 1 SNA
....4 M0131 BN63-00413A
GASKET;MB15KO,CONDUCTIVE
FAB,5MM,8MM,8MM
1 SNA
....4 BN63-06367A SHIELD-LAMP;PLUM 21.5'',SPTE,T0.3 1 SNA
...3 M0126 BN73-00170A
RUBBER-
FOOT;943BW,2043BW,RUBBER,8*8,1.5,
4 SNA
0.1 BN90-02673A
ASSY COVER FRONT;EX2220X,BLACK,HIGH
GLOS
1 SNA
..2 F001A BN96-12854C
ASSY COVER P-FRONT;Cobalt
21.5,ABS+PMMA,
1 SA
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.04,680mm,20 1.13 SNA
...3 F001 BN63-06703C
COVER-FRONT;Cobalt
21.5",PMMA+ABS,HB,BK2
1 SNA
...3 M0007 BN64-01309A KNOB-FUNCTION;Cobalt Project,ABS,BK23 1 SNA
...3 AL093 BN67-00281A LENS-LED;Cobalt Project,PC CLEAR,TP26 1 SNA
...3 BN68-02382B
LABEL-TCO5.0,ENERGY-
STAR;TCO5.0,ENERGY-S
1 SNA
...3 FB01A BN96-13682D
ASSY BOARD
P-FUNCTION;Cobalt,FUNCTION,25
1 SA
....4 BN94-03497C
ASSY PCB FUNCTION-BN96-
13682D;COBALT,BN9
1 SNA
.....5 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.814 SNA
.....5 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.003 SNA
.....5 0204-002420 SOLVENT;1M-1000,C3H70H,96 3.47 SNA
.....5 0204-002607 FLUX;DF-234U,13%,14KG,Gravity 0.82 2.259 SNA
.....5 M2893 BN39-01298C
LEAD CONNECTOR;COBALT,UL1061#28,UL/
CSA,5
1 SNA
.....5 T0174 BN97-04306A ASSY SMD;COBALT, FUNCTION 1 SNA
......6 0202-001477
SOLDER-CREAM;LST309-
M,D20~45um,96.5Sn/3A
0.462 SNA
......6 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 SA
......6 AHR40 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 2 SNA
......6 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 2 SNA
......6 T0313 3404-001379 SWITCH-TACT;12V,50mA,250gf,4.9x4.9x1.5mm 6 SA
......6 HB01A 3711-005743
HEADER-BOARD TO
CABLE;BOX,5P,1R,1.25mm,A
1 SA
......6 BN41-01400B PCB SUB-FUNCTION;Cobalt(all),FR-4,2,1.1, 1 SNA
0.1 BN91-04714A ASSY LCD-ATZ;BX2240 1 SNA
..2 M0215 BN07-00795A LCD-PANEL;M215HW01 V6,AU21507,6bit Hi-FR 1 SA
0.1 M0017 BN91-05267A ASSY CHASSIS-ATZ;LS22CLUSB/EN,EX2220 1 SNA
