Samsung EX2220 - Page 7

3-4
3. Disassembly and Assembly
Description Photo Screws
8. Remove the four (4) screws shown in the gure
and remove the Bracket support.
9. Remove the main PCB and IP boards from the
SHIELD-cover.
※The assembly is in the reverse order of disassembly.
