Samsung Galaxy Z Fold 5 User Manual

Settings
151
•
Palm swipe to capture : Set the device to capture a screenshot when you swipe
your hand to the left or right across the screen. You can check the captured images
in
Gallery . It is not possible to capture a screenshot while using some apps and
features.
Excessive shaking or an impact to the device may cause an unintended input for
some features using sensors.
Video call effects
You can use features that change the background or block background noise during
video calls.
On the Settings screen, tap
Advanced features
→
Video call effects and tap the switch
to turn it on. The
icon will be added on the video calling app’s screen.
Using video call effects
On the video calling app’s screen, tap .
•
Reset all : Reset the settings.
•
Background : Change or blur the background during video calls.
•
Face : Apply beauty effects to the face.
•
Colour tone : Adjust the screen’s colour tone and brightness.
•
Auto framing : Turn the auto framing feature on or off. When you turn on this feature,
the device changes the shooting angle and zoom automatically by recognising and
tracking people during video calls.
•
Mic mode : Block background noise to make the sound clearer.
‒
Standard : Remove noise so that it sounds like a normal voice call.
‒
Voice focus : Focus on the sound coming from the direction of the front camera.
‒
All sound : Transmit all the sounds around you, such as the sound of music.
•
: Select or add background colours or images to use during video calls.
•
Some features may not be available depending on the model.
•
Some features are available only when using the front camera.

Samsung Galaxy Z Fold 5 Specifications

General

Face recognition	Yes
Modulation	1024-QAM
4G standard	LTE-TDD & LTE-FDD
3G standards	UMTS, WCDMA
SIM card type	NanoSIM + eSIM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.3
3G bands supported	850, 900, 1900, 2100 MHz
4G bands supported	700, 800, 850, 900, 1500, 1800, 1900, 2100, 2300, 2500, 2600 MHz
5G bands supported	700, 800, 850, 900, 1800, 1900, 2100, 2300, 2500, 2600, 3500, 3700 MHz
SIM card capability	Dual SIM
Mobile network generation	5G
Talk time (4G)	40 h
Battery capacity	4400 mAh
Standby time (3G)	- h
Browsing time (4G)	17 h
Browsing time (Wi-Fi)	18 h
Continuous audio playback time	73 h
RAM capacity	12 GB
Compatible memory cards	-
Internal storage capacity	512 GB
Screen shape	Flat
Pixel density	374 ppi
Display diagonal	7.6 \
Display brightness	1200 cd/m²
Display resolution	2176 x 1812 pixels
Maximum refresh rate	120 Hz
Gorilla Glass version	Gorilla Glass Victus 2
Second display diagonal	6.2 \
Display number of colors	16 million colors
Second display brightness	1000 cd/m²
Second display resolution	2316 x 904 pixels
Brand specific technologies	Always-on display
Flash type	LED
Digital zoom	30 x
Optical zoom	3 x
Rear camera type	Triple camera
Front camera type	Dual camera
Maximum frame rate	960 fps
Image stabilizer type	Optical Image Stabilization (OIS)
Rear camera resolution	6120 x 8160 pixels
Front camera pixel size	1.22 µm
Rear camera sensor size	1/1.56 \
Front camera sensor size	1/3.24 \
Resolution at capture speed	1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps, 3840x2160@60fps, 7680x4320@30fps
Third rear camera pixel size	1 µm
Second rear camera pixel size	1.12 µm
Third rear camera sensor size	1/3.94 \
Second front camera pixel size	2 µm
Second rear camera sensor size	1/3.21 \
Video capture resolution (max)	4320 x 7680 pixels
Rear camera resolution (numeric)	50 MP
Third rear camera aperture number	2.4
Second rear camera aperture number	2.2
Second front camera aperture number	1.8
Rear camera field of view (FOV) angle	85 °
Third rear camera resolution (numeric)	10 MP
Second rear camera resolution (numeric)	12 MP
Second front camera resolution (numeric)	4 MP
Third rear camera field of view (FOV) angle	36 °
Second rear camera field of view (FOV) angle	123 °
Second front camera field of view (FOV) angle	80 °
Platform	Android
Operating system installed	Android 13
Processor cores	8
Processor model	8 Gen 2
Processor family	Qualcomm Snapdragon
Processor frequency	- GHz
Processor boost frequency	3.36 GHz
Audio system	Dolby Atmos
Audio formats supported	3GA, AAC, AMR, APE, AWB, DFF, DSF, FLAC, IMY, M4A, MID, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, XMF
Video formats supported	3G2, 3GP, AVI, FLV, M4V, MKV, MP4, WEBM
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
Color name	Phantom Black
Form factor	Clamshell
Product color	Black
Housing material	Aluminum
Protection features	Water resistant
International Protection (IP) code	IPX8

Weight and Dimensions

Depth	6.1 mm
Width	129.9 mm
Height	154.9 mm
Weight	253 g
Folded depth	13.4 mm
Folded width	67.1 mm
