- 22 -

7-2 Main Parts List

S.N.A : SERVICE NOT AVAILABLE

LEVEL No. Code No. Description Speciﬁcation Q’ty SA/

SNA

Remark

1-1 M036 4713-001031 LAMP-INCANDESCENT 230V,173mA,40W,ORG,-,- 1 SA

1-1 M038 DE26-00091A TRANS H.V SHV-D700A-1,220V,60HZ,2140V/3. 1 SA

1-1 M049 DE31-10154A MOTOR SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 1 SA

1-1 M030 DE47-20008A THERMOSTAT PW2N-52JC,100/60,250V/7.5A,H, 1 SA

1-1 M001 DE64-00350F PANEL-OUTER RE-C40S,C/STEEL,T0.5,W348.8, 1 SA

1-1 M034 DE67-00140A COUPLER NC2000(0.6~0.8),PPS(ESS840),-, 1 SA

1-1 M022 DE71-00148A COVER-BLOWER MW850WA,PP,T1.5,-,-,-,NTR,N 1 SA

1-1 M051 DE71-00151B COVER-MGT RE-C40,PP,-,W54,L129,-,GRY,NC2 1 SA

1-1 M037 DE71-60457C COVER-AIR 3RD-0.7(BTM),PP(FH44N),-,-,-,- 1 SA

1-1 T001 DE74-20102E TRAY-COOKING NC 0.8,GLASS,T6,890G,-,-,-, 1 SA

1-1 M017 DE96-00010B ASSY NOISE FILTER SN-3WDB,250V10A,NO-INR 1 SA

1-2 M019 3601-000178 FUSE-CARTRIDGE 250V,10A,SLOW-BLOW,GLASS, 1 SA

1-1 M020 DE96-00031D ASSY-MOTOR FAN SMF-3RDDA,220V60HZ,2400RP 1 SA

1-2 M023 DE31-10184C MOTOR FAN -,220V60HZ,-,SMF-3RDDA,2400RPM 1 SA

1-2 H018 DE31-90057A BLADE-FAN PP,T1.5,-,3RD-W,-,-,- 1 SA

1-2 M039 2501-001021 C-OIL 740nF,2100V,BK,35X54X70,20mm 1 SA

1-2 M040 DE61-00139A BRACKET-HVC NC2000,SECC,T0.8,-,-,-,0.6/0 1 SNA

1-2 M047 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2 SA

1-2 M048 DE80-00023A BASE-PLATE MW850WA,SGCC1,T0.6,-,-,NC2000 1 SA

1-2 M041 0402-001554 DIODE-RECTIFIER HV03-12T01,12000V,0.4A,D 1 SA

1-1 B018 DE96-00120W ASSY BODY LATCH M1717N,NC2000 PP (FB53 G 1 SA

1-2 B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1 SA

1-2 B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2 SA

1-2 B010 DE66-00093C LEVER-SWITCH(A) M1717N,NC2000 PP (FB53 G 1 SA

1-2 B011 DE66-00094C LEVER-SWITCH(B) M1717N,NC2000 PP (FB53 G 1 SA

1-2 B006 DE72-00137E LATCH-BODY NC2000(0.6/0.8/1.2),PP(FB53 G 1 SA

1-1 M015 DE96-00252C ASSY POWER CORD EU(ST),DOMESTIC,220V/60H 1 SA

1-1 W002 DE96-00419A ASSY-WIRE HARNESS A RE-C230T-1,CMO 1 SA

1-1 T017 DE97-00193B ASSY-GUIDE ROLLER NC2000 0.8,T2*P1198(14 1 SA

1-1 M035 OM75S(31)ESNY ASSY-MGT 1 SA
