Exploded View and Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC Description SEC CODE
QSP01 SPEAKER
3001-002587
QCR17 SCREW-MACHINE
6001-001460
QCR12 SCREW-MACHINE
6001-001530
QCR93 SCREW-MACHINE
6001-002263
QMI01 MICROPHONE-ASSY-GT-E2550 GH30-00656A
QBA01 INNER BATTERY PACK-800MAH,BLK,UNI,MAIN GH43-03257A
QCA01 CAMERA MODULE-GT-C5010(1.3M) GH59-09031A
QLC02 ASSY ETC-LCD SUB PBA(GT-E2550) GH59-09170A
QME16 ASSY ETC-CON TO CON FPCB(GT-E2550) GH59-09171A
QMO01 MODULE-MOT/RCV FPCB(GT-E2550) GH59-09178A
QME01 DOME SHEET-GT-E2550 MAIN GH59-09200A
QME02 DOME SHEET-GT-E2550 SUB GH59-09201A
QMP01 A/S ASSY-GTE2550_PBA MAIN
(
SVC) GH82-04897A
QLC01 ASSY LCD-2.0" QQVGA STD SLIDE LCM WINTE GH96-04490A
QFU01 ASSY CASE-SLIDE UPPER GH98-16574A
QKP02 ASSY KEYPAD-SUB GH98-16579A
QKP01 ASSY KEYPAD-MAIN(3X4) GH98-16580A
QFR01 ASSY CASE-FRONT GH98-16838A
QMW01 ASSY COVER-MAIN WINDOW GH98-16840A
QFL01 ASSY CASE-SLIDE LOWER GH98-16917A
QBC00 ASSY COVER-BATTERY GH98-17273A
QRE01 ASSY CASE-REAR GH98-16839A
QAN02 INTENNA-MAIN(GT-E2550) GH42-02471A
QIF01 PMO COVER-IF GH72-59679A
5-2.
Cellular phone Parts list
