Samsung Electronics 5-2
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Part List
Loc. No. Part No. Description;Specification Qty. SNA Remark
AD330 AH64-05292B DECORATION-SIDE-L;HT-C5500,ABS,2.5,350,5 1 SNA
AD340 AH64-05293B DECORATION-SIDE-R;HT-C5500,ABS,2.5,350,5 1 SNA
AD504 AH64-05321B DOOR-HIDDEN;HT-C5500,ABS+PMMA,2.2,25,80, 1 SNA
AF020 AH63-02108A FILTER-VFD;HT-C5500,PC,0.5T,90,25,VIOLET 1 SNA
AS078 AH63-02006A SHEET-FUNCTION;HT-BD3250,PC T0.3,0.3,156 1 SNA
AS102 AH63-02007A SHEET-POWER;HT-BD3250,PC T0.3,0.3,100,15 1 SNA
C011 AH61-02527A SPRING ETC-DOOR;HT-Z310,STS 304 WPS,0.2, 1 SA
CC02 AH64-05291F CHASSIS-BOTTOM;HT-C5500,EGI-SECC,0.8,430 1 SNA
D001A AK96-01214J ASSY ENGINE P-BD DECK;BD-P6C,OEM,1B 1 SNA
EF01 3103-001251 FAN-DC;12,80mA,2000rpm,0.11m^3/mi,0.62mm 1 SA
ES19 AH61-03102A SPRING ETC-HIDDEN;HT-C6500,STAINLESS-STS 1 SA
F001 AH63-02130A COVER-FRONT;HT-C5500,ABS+PMMA,2.2,430,80 1 SNA
FD23 AH64-05320A DOOR-BD;HT-C5500,ABS+PMMA,2.2,15,100,3,B 1 SA
FK01A AH96-00175B ASSY KNOB P-VOLUME;HT-C5500,BASIC,PMMA+A 1 SNA
FL06 3809-002517 FFC CABLE-FLAT;30V,80C,100mm,28P,1.0mm,U 1 SA
FL06 3809-002518 FFC CABLE-FLAT;30V,80C,220mm,28P,1.0mm,U 1 SA
FL261 3809-002351 FFC CABLE-FLAT;30V,80C,185mm,5P,1.0mm,UL 1 SA
FL261 3809-002357 FFC CABLE-FLAT;30V,80C,90mm,15P,1.0mm,UL 1 SA
FL261 3809-002359 FFC CABLE-FLAT;30V,80C,45mm,5P,1mm,UL206 1 SA
HKF01 AH61-02963A HOLDER-KEY FUNCTION;HT-BD3250,ABS,13,60, 1 SNA
M0014 AH94-02433F ASSY PCB MAIN;HT-C5500,BD HOME THEATER,E 1 SA
MA01A AH94-02430B ASSY PCB AMP;HT-C5500,BD HOME THEATER,EP 1 SA
MF01A AH94-02431C ASSY PCB FRONT;HT-C5200,BD HOME THEATER, 1 SA
MK01A AH94-02432B ASSY PCB KEY;HT-C5500,BD HOME THEATER,FR 1 SNA
P001A AH94-02449D ASSY PCB SMPS;HT-C5500_220V,BD HTS,1 1 SA
T001 AH63-02119B COVER-TOP;HT-C5500,ABS,2.5,350,58,BLK 1 SA
T0268 3903-000403 CBF-POWER CORD;AT,EU,CP2,HOUSING(2P),250 1 SA
W275 6003-001561 SCREW-TAPTYPE;BH,+,-,B,M3,L6,ZPC(WHT),SW 14 SA
W384 6002-000126 SCREW-TAPPING;FH,+,-,2S,M3,L10,ZPC(BLK), 2 SA
W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 16 SA
To Next Page
