Samsung HT-C5200 Service Manual

Samsung Electronics 5-6
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
5-4 Electrical Part List
Loc. No. Part No. Description Specification Qty. SNA Remark
MA01A AH94-02430B ASSY PCB AMP HT-C5500,BD HOME THEATER,EP 1 SA
6MC22 2203-000975 C-CER,CHIP 47nF,10%,25V,X7R,TP,1608,- 1 SNA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 71 SNA
AAR39 2007-000123 R-CHIP 1.5Kohm,5%,1/10W,TP,1608 1 SA
AC10 2203-000531 C-CER,CHIP 2.7nF,10%,50V,X7R,1608 6 SNA
AC139 2203-000491 C-CER,CHIP 2.2nF,10%,50V,X7R,1608 3 SA
AC510 3708-001981 CONNECTOR-FPC/FFC/PIC 28P,1mm,SMD-S,SN,N 1 SNA
AD480 2203-000203 C-CER,CHIP 100nF,10%,16V,X7R,TP,2012,2mm 2 SA
AD480 2203-001386 C-CER,CHIP 100nF,10%,100V,X7R,TP,3216,3. 4 SNA
AD480 2203-006336 C-CER,CHIP 10000nF,10%,25V,X5R,3216 9 SA
AD480 2203-006698 C-CER,CHIP 1000nF,10%,25V,X7R,1608 2 SNA
AD480 2203-006706 C-CER,CHIP 2200nF,10%,50V,X7R,3225 1 SNA
AD480 2203-007176 C-CER,CHIP 10000nF,10%,16V,X5R,TP,2012 ( 14 SNA
AH025 AH62-00223A HEAT SINK-AMP HT-C5500,ALLUMINUM,3T,100, 1 SNA
AH260 AH61-02854A HOLDER-HEATSINK HT-BD1250,HIPS V0,2.0mm, 2 SNA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 1 SA
AR108 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 15 SA
AR150 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 9 SA
AR158 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 1 SA
AR174 2007-000129 R-CHIP 27Kohm,5%,1/10W,TP,1608 5 SA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 5 SA
AR42 2007-000939 R-CHIP 47Kohm,1%,1/10W,TP,1608 3 SA
ARR2 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 1 SA
C 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.2m 3 SA
C 2402-001218 C-AL,SMD 22UF,20%,35V,WT,TP,6.6X6.6X5.8M 2 SA
C 2401-004106 C-AL 680uF,20%,50V,-,BK,12.5 x 35,5 6 SNA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 5 SC
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 2 SA
C24 2203-005565 C-CER,CHIP 1nF,5%,50V,NP0,TP,1608 9 SA
C4N08 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,1608 3 SNA
CER02 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 1 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 1 SA
D0254 0402-001090 DIODE-SCHOTTKY MBRS1100,100V,1000MA,DO-2 1 SNA
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 5 SA
DR01A 0402-001427 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 3 SA
DR01A 0402-001614 DIODE-RECTIFIER S1G,400V,1A,DO-214AC,TP 6 SA
DR1 2007-000043 R-CHIP 1Kohm,1%,1/10W,TP,1608 3 SA
DS01A 0401-001166 DIODE-SWITCHING BAV20WS-V,150V,250mA,SOD 3 SA
ER19 2007-002899 R-CHIP 10ohm,1%,1/10W,TP,1608 4 SA
FAN1 3711-000820 HEADER-BOARD TO CABLE BOX,2P,1R,2.5MM,ST 1 SA
FAR22 2007-000082 R-CHIP 3.3Kohm,5%,1/10W,TP,1608 1 SNA
FD7 0601-001226 LED SMD(TOP VIEW),RED,1.2x0.8mm,660nm,1. 7 SNA
FL06 3809-002517 FFC CABLE-FLAT 30V,80C,100mm,28P,1.0mm,U 1 SA
FMR4 2007-000080 R-CHIP 2Kohm,5%,1/10W,TP,1608 6 SNA
HR13 2007-000821 R-CHIP 390ohm,1%,1/10W,TP,1608 3 SNA
IDR23 2007-000116 R-CHIP 120ohm,5%,1/10W,TP,1608 1 SNA
JP19 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 6 SA
KAC5 2203-001126 C-CER,CHIP 0.68nF,10%,50V,X7R,1608 6 SNA
