Samsung HT-C5200 Service Manual

Samsung Electronics 5-10
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
HDR2 2007-000151 R-CHIP 15Kohm,5%,1/16W,TP,1005 3 SNA
HDR7 2007-000139 R-CHIP 220ohm,5%,1/16W,TP,1005 2 SNA
HDR7 2007-000570 R-CHIP 220ohm,1%,1/10W,TP,1608 1 SA
HE4 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 17 SA
HR8 2703-000166 INDUCTOR-SMD 2.7uH,5%,3225 2 SA
HRP2 2011-001344 R-NETWORK 100ohm,5%,1/16W,L,CHIP,8P,TP,2 14 SA
IC104 0801-002518 IC-CMOS LOGIC 74LCX157,2-INPUT MULTIPLEX 3 SA
IC104 0801-002564 IC-CMOS LOGIC 74VHCT244A,BUFFER,TSSOP,20 1 SA
IC112 1103-001410 IC-EEPROM S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 2 SNA
IC113 1105-002066 IC-DRAM K4B1G1646E-HCH9,DDR3 SDRAM,1Gbit 1 SNA
IC113 1105-002083 IC-DRAM K4B1G0846E-HCH9,DDR3 1G SDRAM,1G 2 SNA
IC520 0903-001565 IC-MICROCONTROLLER LC87F5NC8AVU,QFP,100P 1 SNA
IC520 0903-001638 IC-MICROCONTROLLER EPF005N,LQFP,64P,7x7m 1 SNA
IC520 0903-001642 IC-MICROCONTROLLER EP94A2K,LQFP,128P,14x 1 SNA
JA333 3722-003021 JACK-PIN 6P (W/L),NI+SN,RED/BLU/GRN/YEL/ 1 SNA
JC10 2203-006324 C-CER,CHIP 2200nF,10%,10V,X5R,1608 1 SA
JC31 2203-000715 C-CER,CHIP 3.3nF,10%,50V,X7R,1608 3 SNA
KAR11 2007-000124 R-CHIP 2.2Kohm,5%,1/10W,TP,1608 2 SNA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 2 SA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 1 SNA
KOP1 1201-000163 IC-OP AMP 4560,SOP,8P,173MIL,DUAL,100V/m 1 SA
KQ1 0501-000279 TR-SMALL SIGNAL KSA1182-Y,PNP,150mW,SOT- 2 SA
KR7 2007-000402 R-CHIP 150ohm,5%,1/10W,TP,1608 4 SA
L8 2703-000402 INDUCTOR-SMD 1uH,20%,3225 3 SNA
MC2 2203-000254 C-CER,CHIP 10nF,10%,16V,X7R,TP,1005 6 SA
MC9 2203-000627 C-CER,CHIP .022nF,5%,50V,C0G,TP,1005 4 SNA
MIC2 1105-001573 IC-DRAM K4S281632,-,128Mbit,8Mx16Bit,TSO 1 SA
MR10 2007-007141 R-CHIP 240ohm,5%,1/16W,TP,1005 1 SNA
MR103 2007-000308 R-CHIP 10ohm,5%,1/8W,TP,2012 6 SA
MR11 2007-008015 R-CHIP 75ohm,1%,1/16W,TP,1005 14 SNA
MR122 2007-000094 R-CHIP 22Kohm,5%,1/10W,TP,1608 1 SA
MR13 2007-000157 R-CHIP 47Kohm,5%,1/16W,TP,1005 26 SNA
MR16 2007-000168 R-CHIP 470Kohm,5%,1/16W,TP,1005 2 SNA
MR306 2007-000141 R-CHIP 2.2Kohm,5%,1/16W,TP,1005 4 SNA
MR39 2007-000242 R-CHIP 1.5Kohm,5%,1/16W,TP,1005 7 SNA
MR604 2007-000137 R-CHIP 2Kohm,5%,1/16W,TP,1005 2 SNA
MR8 2007-000503 R-CHIP 2.2ohm,5%,1/10W,TP,1608 3 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 1 SA
MX1 2801-004284 CRYSTAL-SMD 27MHz,10ppm,28-AAN,20pF,30oh 1 SA
OTR1 2007-001292 R-CHIP 33ohm,5%,1/16W,TP,1005 87 SNA
PC11 2203-006141 C-CER,CHIP 1000nF,10%,16V,X5R,1608 5 SNA
PC43 2203-000233 C-CER,CHIP 0.1nF,5%,50V,C0G,TP,1005 2 SA
PPC2 2203-005148 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 5 SNA
PPR2 2007-000343 R-CHIP 120ohm,1%,1/10W,TP,1608 3 SA
PR12 2007-000979 R-CHIP 5.6Kohm,1%,1/10W,TP,1608 2 SA
PR2 2007-000651 R-CHIP 27Kohm,1%,1/10W,TP,1608 1 SA
PR4 2007-000052 R-CHIP 10Kohm,1%,1/10W,TP,1608 2 SA
Q373 0501-000546 TR-SMALL SIGNAL KSA1298,PNP,200mW,SOT-23 1 SNA
