PCB Diagram
6-4-1 Pin Connection
1 CON4
AMP Power Connector
Pin No. Signal
1 VARIABLE PWR C
2 PVDD -30V
3 PVDD -30V
4 PVDD -30V
5 SGND
6 SGND
7 SGND
8 PVDD +30V
9 PVDD +30V
10 PVDD +30V
2 CON1
Audio Data / PWM IC Interface
Connector
Pin No. Signal
1 MIC PDN
2 FAN PWR
3 FAN SEN
4 AUOUT3
5 AUOUT2
6 AUOUT1
7 AUOUT0
8 LRCKOUT
9 BCLKOUT
10 GND
11 SO PWM
12 SCK PWM
13 CS PWM
14 SI PWM
15 RESET PWM
16 EXT MUTE
17 RESET POWER
18 SD POWER
19 VARI A
20 VARI B
21 GND
22 AMP3.3V
23 GND
24 AMP -12V
25 GND
26 GND
27 AMP -12V
28 GND
