Samsung HW-A430 - Bottom Panel Connections; Optical Digital Audio Input; USB Port for Media Playback; AC Power Connection Port

ENG - 4
Bottom Panel of the Soundbar
USB (5V 0.5A)
DIGITAL AUDIO IN
(OPTICAL)
POWER
USB (5V 0.5A)
DIGITAL AUDIO IN
(OPTICAL)
POWER
󱂓
󱂕
󱂔
󱂓
DIGITAL AUDIO IN (OPTICAL)
Connect to the digital (optical) output of an external device.
󱂔
USB (5V 0.5A)
Connect a USB device here to play music les stored on the USB device through the Soundbar.
󱂕
POWER
Connect the Soundbar's AC power cable.
• When disconnecting the power cord from a wall outlet, pull the plug. Do not pull the cable.
• Do not connect this unit or other components to an AC outlet until all connections between
components are complete.
