English - 9
Using a Component (up to 1080p) or an Audio/Video (480i only) and a Scart Cable
✎
In Ext. mode, DTV Out supports MPEG SD Video and Audio only.
✎
When connecting to AV IN, the colour of the AV IN [VIDEO] jack (green) will not match the video cable
(yellow).
✎
To obtain the best picture quality, the Component connection is recommended over the A/V
connection.
AUDIO OUT
R-AUDIO-L
P
R
P
B
Y
COMPONENT OUT
EXT
AUDIO OUT
R-AUDIO-L
VIDEO OUT
Y
R W
Y
RW
R
R
B
B
G
G
R
R
W
W
Component connection
AV connection
SCART connection
[UD6500-RU]BN68-03482J-01L04.indb 9 2011-05-09 오후 3:59:41
