5. Exploded View & Part List
5-20. LE46B65*A Parts List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
LE46B653T5WXXC LE46B653T5W,N68A/46BT5-G6T,46,LCD-TV,SPA
0.1 M0001 BN90-01898B ASSY COVER FRONT;46,LB650,EO,ROSE BLACK, 1 S.N.A
..2 T0175 BN96-09463D ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:70 1 S.A
..2 T0003 BN96-09490B ASSY COVER P-FRONT;46,LB650,EO,PC(CLR)+P 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 BN60-00027H SPACER-FELT;L650-46,FELT,1020,0.5,20 2 S.N.A
...3 T0069 BN60-00027Q SPACER-FELT;L650 46,FELT,570,0.5,20 2 S.N.A
...3 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 7 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.9 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 3.1 S.N.A
...3 CCM1 BN63-05199H COVER-SHEET;AMBER,PE,T0.08,W130mm,200M,C 1.3 S.N.A
...3 M0112 BN63-05275B COVER-FRONT;46,LB650,EO,PC(CLR)+PC(ROSE 1 S.N.A
....4 BN81-00116D RESIN-TOC;PC V0,TTP01,CLR,TN-1030(NP),TH 0.957 S.N.A
....4 BN81-00116U RESIN-TOC;PC V1, TRD03,Light Rose Black, 1.018 S.N.A
...3 BN96-09511C ASSY HOLDER P-BOSS SIDE RIGHT;46,LB650,A 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.3 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.43 S.N.A
....4 BN61-04760C HOLDER-BOSS SIDE R;46,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.09 S.N.A
...3 BN96-09511D ASSY HOLDER P-BOSS SIDE LEFT;46,LB650,AB 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.3 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.43 S.N.A
....4 BN61-04760D HOLDER-BOSS SIDE L;46,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.09 S.N.A
...3 BN96-09521B ASSY HOLDER P-BOSS BOTTOM;46,LB650,ABS,H 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.5 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.82 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.07 S.N.A
....4 BN61-04828B HOLDER-BOSS BOTTOM;46,LB650,ABS,HB,WH12, 1 S.N.A
.....5 BN81-00116F RESIN;ABS HB,WHT,HF-0680U,W91902,-,-,- 357.5 S.N.A
...3 M0175 BN96-10210B ASSY BOARD P-TOUCH FUNCTION&IR;LN40B650T 1 S.A
0.1 M0002 BN90-01911A ASSY COVER REAR;46,LB650,EO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 12 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 M0013 BN96-09508A ASSY COVER P-REAR;46,LB650,EO,ABS+PMMA,H 1 S.A
...3 BN63-01151A FELT-NON WOVEN;MM17NS,-,T0.5,393,10,BLK, 2 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.9 S.N.A
...3 BN63-02224A FELT-VIBRATION;63P5,FELT,T0.5,850,10 1 S.N.A
...3 M0006 BN63-05280A COVER-REAR;46,LB650,EO,PMMA+ABS,HB,BK23, 1 S.N.A
....4 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 3.883 S.N.A
...3 T0071 BN64-01028A INLAY-TERMINAL;B530 (PAL-Chelsea),PS SHE 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
0.1 M0112 BN91-03504A ASSY SHIELD;LE46B653T5WXXC 1 S.N.A
