Samsung LE32D550K1W User Manual

English - 16
Securing the TV to the Wall
Caution: Pulling, pushing, or climbing onto the TV may cause the TV to fall. In particular, ensure that your
children do not hang over or destabilize the TV; doing so may cause the TV to tip over, resulting in serious
injuries or death. Follow all safety precautions provided on the included Safety Flyer. For added stability, install
the anti-fall device for safety purposes, as follows.
To avoid the TV from falling
1. Put the screws into the clamps and firmly fasten them onto the
wall. Confirm that the screws have been firmly installed onto the
wall.
✎ You may need additional material such as an anchor
depending on the type of wall.
✎ Since the necessary clamps, screws, and string are not
supplied, please purchase these additionally.
2. Remove the screws from the centre back of the TV, put the
screws into the clamps, and then fasten the screws onto the TV
again.
✎ Screws may not be supplied with the product. In this case,
please purchase the screws of the following specifications.
✎ Screw Specifications
x
For a 32 ~ 40 Inch LCD TV: M6
x
For a 46 ~ 55 inch LCD TV: M8
3. Connect the clamps fixed onto the TV and the clamps fixed onto
the wall with a strong string and then tie the string tightly.
✎ NOTE
x
Install the TV near to the wall so that it does not fall backwards.
x
It is safe to connect the string so that the clamps fixed on the wall are equal to or lower than the clamps fixed on
the TV.
x
Untie the string before moving the TV.
4. Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have any
doubt about the security of your connections, contact a professional installer.
Storage and Maintenance
✎ If you remove the attached sticker on the TV screen, clean the residues and then watch TV.
Do not spray water or a cleaning agent directly onto the
product. Any liquid that goes into the product may cause a
failure, fire, or electric shock.
Clean the product with a soft cloth dapped in a small amount
of water.
Wall
[LD550-580-XU]BN68-03397J-Eng.indd 16 2011-02-22 �� 3:41:31

Samsung LE32D550K1W Specifications

General

Audio system	Stereo, Dolby Digital Plus, SRS TheaterSound
RMS rated power	20 W
Number of speakers	2
Package depth	160 mm
Package width	1000 mm
Package height	600 mm
Package weight	12900 g
Number of tuners	1 tuner(s)
Auto channel search	Yes
Digital signal format system	DVB-C, DVB-T
RS-232 ports	0
HDMI ports quantity	4
Card reader integrated	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Annual energy consumption	85 kWh
Product color	Black
LED indicators	Stand-by
Panel mounting interface	200 x 200 mm
Display diagonal	32 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	50 Hz
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720i, 720p
Display diagonal (metric)	80 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Remote control type	TM950
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	110 W
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W

Weight and Dimensions

Depth (with stand)	240 mm
Width (with stand)	804.7 mm
Height (with stand)	563.7 mm
Weight (with stand)	11500 g
Depth (without stand)	77.8 mm
Height (without stand)	507.4 mm
Weight (without stand)	8800 g
