Samsung LE40F86BD - Page 259

6-3
6. Wiring Diagram
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21
12V 12V 12V 12V
GND GND GND GND
RO [0]-
RO [0]+
RO [1]-
RO [1]+
RO [2]-
RO [2]+
ROCLK-
ROCLK+
RO [3]-
RO [3]+
RO [4]-
RO [4]+
NC
22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41
NC
RE [0]-
RE [0]+
RE [1]-
RE [1]+
RE [2]-
RE [2]+
RECLK-
RECLK+
RE [3]-
RE [3]+
RE [4]-
RE [4]+
NC NC
SCL
SDA
WP
LVDS OPTION
DCC SEL
1 2 3 4 5
SW_INVERTER ANA_DIMMING_OUT PWM_DIMMING_OUT GND NC
CN1103(to Panel)
1 2 3 4 5 6 7 8 9
10 11
HDMI1_RX2+ GND HDMI1_RX2- HDMI1_RX1+ GND HDMI1_RX1- HDMI1_RX0+ GND HDMI1_RX0- HDMI1_RXCLK+ GND
12 13 14 15 16 17 18 19 20 21
HDMI1_RXCLK- NC NC HDMI1_DDC_SCL HDMI1_DDC_SDA GND 5V 5V GND GND
JA801(to HDMI1)
1 2 3 4 5 6 7 8 9
10 11
HDMI2_RX2+ GND HDMI2_RX2- HDMI2_RX1+ GND HDMI2_RX1- HDMI2_RX0+ GND HDMI2_RX0- HDMI2_RXCLK+ GND
12 13 14 15 16 17 18 19 20 21
HDMI2_RXCLK- NC NC HDMI2_DDC_SCL HDMI2_DDC_SDA GND 5V 5V GND GND
JA803(to HDMI2)
1 2 3 4 5 6 7 8 9
10
HDMI3_RX2+ GND HDMI3_RX2- HDMI3_RX1+ GND HDMI3_RX1- HDMI3_RX0+ GND HDMI3_RX0- HDMI3_RXCLK+
11 12 13 14 15 16 17 18 19
GND HDMI3_RXCLK- HDMI_CEC NC HDMI2_DDC_SCL HDMI2_DDC_SDA GND 5V 5V
JA701B(to HDMI3)
1 2 3 4 5 6 7 8
PC_RED PC_GREEN PC_BLUE GND GND GND GND GND
9
10 11 12 13 14 15
5V PC_IDENT GND EMU_SDA PC_HS_MICOM PC_VS_SVP EMU_SCL
CN1101(to PC)
1 2 3 4 5 6 7 8 9
10 11 12
NC
SW_POWER
PGND
A5V
GND GND
B18VS B18VS
PGND PGND PGND PGND
13 14 15 16 17 18 19 20 21 22 23 24
B5V B5V B5V B5V
PGND PGND PGND
B13 B13 B13
NC NC
POWER(CN1101) DIMMING(CN2703_LCD)
1 2 3 4 5 6
GND DVI_SR_IN DVI_SL_IN GND DVI_SL_IN DVI_SR_IN
JA804(to DVI Sound)
1 2 3 4 5 6 7
GND PC_SR_IN PC_SL_IN PC_SL_IN PC_SL_IN PC_SR_IN PC_SR_IN
JA802(to PC Sound)
1 2 3 4 5 6 7
GND R2IN T2OUT T2OUT T2OUT R2IN R2IN
JA609(to Service Jack)
1 2 3 4 5 6 7 8 9
10 11
GND HP_OUT_L HP_OUT_R NC HP_IDENT GND NC HP_IDENT GND NC NC
JA702B(to Headphone)
1 2 3 4 5 6 7 8 9
GND VIDEO2_IDENT VIDEO2_CVBS GND VIDEO2_SR_IN VIDEO2_SL_IN GND VIDEO2_SL_IN VIDEO2_SR_IN
CN701B(to Video2)
1 2 3 4 5 6 7 8 9
10 11
GND GND GND SVHS2_C SVHS2_Y NC GND SVHS2_IDENT NC GND SVHS2_IDENT
CN702B(to S-Video2)
1 2 3 4
USB_VCC USB2_DN USB2_DP GND
CN704B(to USB)
1 2 3 4 5 6 7 8 9
GND VIDEO1_IDENT VIDEO1_CVBS GND VIDEO1_SR_IN VIDEO1_SL_IN GND VIDEO1_SL_IN VIDEO1_SR_IN
JA602(to Video1)
1 2 3 4 5 6
SVHS1_C SVHS1_Y GND GND SVHS1_IDENT GND
JA605(to S-Video1)
1 2 3 4
R+_OUT R-_OUT L+_OUT L- _OUT
SOUND AMP(CN1201)
1 2 3
VIN VCC GND
OP601(to Optical Jack)
1 2 3 4 5 6
GND MONITOR_SL_OUT MONITOR_SL_OUT GND MONITOR_SR_OUT MONITOR_SR_OUT
JA608(to Sound Output)
1 2 3 4 5 6
GND COMP1_SR_IN COMP1_SL_IN GND COMP1_SL_IN COMP1_SR_IN
JA604(to Component1)
1 2 3 4 5 6
GND COMP2_SR_IN COMP2_SL_IN GND COMP2_SL_IN COMP2_SR_IN
JA607(to Component2)
1 2 3 4 5 6 7 8 9
GND COMP1_IDENT COMP1_Y GND COMP1_PB COMP1_PB GND COMP1_PR COMP1_PR
JA601(to Component1)
1 2 3 4 5 6 7 8 9
GND COMP2_IDENT COMP2_Y GND COMP2_PB COMP2_PB GND COMP2_PR COMP2_PR
JA606(to Component2)
