5-10
5. Exploded View & Part List
5-4. LE40F86BD Parts List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
LE40F86BDX/XEH LE40F86BD,N39A/40F80-GPY,40,LCD-TV,HUNGA
0.1 M0001 BN90-01357B ASSY COVER FRONT;Peony 40F8 1 S.N.A
..2 T0003 BN96-05946C ASSY COVER P-FRONT;-,PEONY 40F8,EU(iDTV) 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 5 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 5 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0112 BN63-03771D COVER-FRONT;ROSE 40F8,ABS+PMMA,-,-,-,HB, 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 M0251 BN96-05877A ASSY DECORATION P-POWER;-,PEONY,40,57,AB 1 S.A
....4 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 1 S.N.A
....4 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
....4 BN61-03460A BOSS-TAPE;PEONY ROSE,TAPE,0.15,DOUBLE-FA 2 S.N.A
....4 M0732 BN64-00680A DECORATION-TOP;PEONY 40,ABS,HB,NATURAL,P 1 S.N.A
....4 BN64-00681A DECORATION-MIDDLE;PEONY 40,PC CLEAR 1 S.N.A
....4 BN64-00682A DECORATION-BOTTOM;PEONY 40,ABS,HB,NATURA 1 S.N.A
....4 M0146 BN96-06151B ASSY BOARD P-POWER SWITCH;LNT4081FX/XAA, 1 S.A
...3 BN96-05949C ASSY DECORATION P-RIGHT;-,PEONY 40F8,EU, 1 S.N.A
....4 T0081 6002-000130 SCREW-TAPPING;FH,+,2S,M4,L12,ZPC(BLK),SM 4 S.N.A
....4 T0527 BN64-00653A GRILLE-SPEAKER;40 PEONY,PET SHEET,T0.25 1 S.N.A
....4 BN64-00672A DECORATION-SIDE,REAR;PEONY 40,PC CLEAR,B 1 S.N.A
....4 BN64-00673D DECORATION-SIDE,FRONT;40F81,EU,PC CLEAR, 1 S.N.A
....4 BN64-00674A DECORATION-SIDE,MIDDLE;PEONY 40,ABS,HB,B 1 S.N.A
....4 M0175 BN96-06153B ASSY BOARD P-TOUCH FUNCTION;LNT4681FX/XA 1 S.A
...3 BN96-05950A ASSY DECORATION P-SIDE L;-,PEONY 40F8,-, 1 S.N.A
....4 T0081 6002-000130 SCREW-TAPPING;FH,+,2S,M4,L12,ZPC(BLK),SM 4 S.N.A
....4 T0527 BN64-00653A GRILLE-SPEAKER;40 PEONY,PET SHEET,T0.25 1 S.N.A
....4 BN64-00672A DECORATION-SIDE,REAR;PEONY 40,PC CLEAR,B 1 S.N.A
....4 BN64-00673A DECORATION-SIDE,FRONT;40F81,ABS,CLEAR,-, 1 S.N.A
....4 BN64-00674A DECORATION-SIDE,MIDDLE;PEONY 40,ABS,HB,B 1 S.N.A
...3 BN96-05956B ASSY HOLDER P-BOSS;PEONY 40F8,HIPS HB,BK 1 S.N.A
....4 BN61-03261B BOSS-TAPE;Tulip,ACRYL,T1.1,W20mm,GRAY,TA 0.53 S.N.A
....4 BN61-03261D BOSS-TAPE;PEONY ROSE,TAPE,1.1,6,GRAY,DOU 0.17 S.N.A
....4 BN61-03333B HOLDER-BOSS BOTTOM;40 PEONY,HIPS HB,BLK 1 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 0.7 S.N.A
...3 BN63-01925A FELT-VIBRATION;42D5,FELT,T0.35,10,370 2 S.N.A
...3 T0714 BN96-06152B ASSY BOARD P-IR;LNT4681FX/XAA,CT5000-536 1 S.A
..2 T0175 BN96-06038A ASSY SPEAKER P;8ohm,Peony/Rose 40”,Mid-R 2 S.A
0.1 M0002 BN90-01360B ASSY COVER REAR;Peony 40F8 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0013 BN96-05957A ASSY COVER P-REAR;-,PEONY 40F8,EU(IDTV), 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0101 BN61-03348A BRACKET-WALL;LCD TV 32”,SECC T1.6 2 S.N.A
...3 M0006 BN63-03774A COVER-REAR;40 PEONY,HIPS,-,-,-,HB,EUP(ID 1 S.N.A
