5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0069 AA60-00171V SPACER-FELT;BE46PS,FELT,500,T0.35,10 2 S.N.A
...3 T0071 BN64-00556D INLAY-TERMINAL;PEONY40,PS SHEET,T0.5,EO, 1 S.N.A
0.1 M0216 BN90-01363A ASSY STAND;Peony 40” 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0027 BN96-05961A ASSY STAND P-BASE;-,PEONY 40F8,-,ABS+PMM 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 6 S.A
...3 BN61-02247A HOLDER-SWIVEL RING;40R71,ACETAL,BLK 1 S.N.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02885A HOLDER-SWIVEL RING;MURANO40,ACETAL NATUR 1 S.N.A
...3 BN61-02886A BRACKET-HINGE SWIVEL;BORDEAUX PLUS,40,SE 1 S.N.A
...3 BN61-03106A BRACKET-STAND BOTTOM;TULIP-SIDE 40,SECC, 1 S.N.A
...3 T0920 BN61-03334A GUIDE-STAND;40 PEONY,ABS V0,BLK 1 S.N.A
...3 T0004 BN63-03369A COVER-STAND BASE;TULIP-SIDE 40,ABS+PMMA, 1 S.N.A
...3 BN63-03373A COVER-STAND DECORATION;TULIP-SIDE 40,ABS 1 S.N.A
...3 BN63-03667A COVER-STAND SUB;40 PEONY,ABS,V0,BLK,H/GL 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,CR Rubber Gray,T1.5 6 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 BN96-06323A ASSY BRACKET P-SUPPORT STAND;-,PEONY40,- 1 S.N.A
....4 T0514 BN61-03440A BRACKET-SUPPORT;ROSE-PEONY 40,SECC,T2.0, 2 S.N.A
0.1 M0017 BN91-01697G ASSY CHASSIS;LE40F86BDX/*,AMLCD 72% 1 S.A
..2 M0014 BN94-01412J ASSY PCB MAIN-AMLCD VE;LE40F86BDX/*,AMLC 1 S.N.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA1803_OP 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 JA1605_NSI 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 JA3601_EU 3709-001497 CONNECTOR-CARD SLOT;68P,1.27mm,ANGLE,AU, 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA1801_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA1802_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001163 JACK-VHS;4P,AU,BLK,ANGLE 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002543 JACK-PIN;3P,Sn,RED/WHT/YEL,ANGLE 1 S.A
...3 CN3201_NSI 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 1 S.N.A
...3 CIS3 BN40-00096A TUNER;DNOS403MH261B(S),PAL Hyper,181CH, 1 S.A
...3 T0174 BN97-01721J ASSY SMD;LE40F86BDX/*,AMLCD 72% 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45##,96.5Sn/ 4.99 S.N.A
....4 D1105 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
