Samsung LE40M86BDX - Pin Assignments; DVI-D

14 Reference Infomation
14-4
14-2-1 DVI-D
14-2 Pin Assignments
NC
DDC Input power (+5V)
IDENT-DVI
Output Signal (HDCP Control)
Rx0-
Rx0+
GND
NC
NC
GND
RxC+
RxC-
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
Rx2-
Rx2+
GND
NC
NC
DDC - SCL
DDC - SDA
NC
Rx1-
Rx1+
GND
NC
Sync
Type
Pin No.
24P DVI-D
Figure 1.
