Samsung LN40C500F3F - Component and A;V Connections

10
English
Connections
Using a Component (up to 1080p) or Audio/Video (480i only) Cable
Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR
✎ For better picture quality, the Component connection is recommended over the A/V connection.
Using an EX-Link Cable Connection
Available devices: External devices that support EX-Link.
EX-LINK: Connector for service only.
R
W
R GB
R W
Y
R
W
R GB
R
W
R
W
R
W
R B G
Y
Y
VIDEO OUT
PR PB Y
COMPONENT OUT
AUDIO OUT
R-AUDIO-L
AUDIO OUT
R-AUDIO-L
Device
Device
Red
RedRed
White
BlueWhite
Yellow
Green
Audio Cable
(Not Supplied)
Component Cable
(Not Supplied)
Video Cable
(Not Supplied)
Audio Cable
(Not Supplied)
