TR17 2001-000802 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
TR24 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR25 2001-000008 R-CARBON;15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR3 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
TR32 2001-000302 R-CARBON;10ohm,5%,1/8W,AA,TP,1.8x3.2mm
TR35 2001-000563 R-CARBON;27Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR37 2001-000563 R-CARBON;27Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR38 2001-000117 R-CARBON(S);68ohm,5%,1/2W,AA,TP,2.4x6.4m
TR39 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR43 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR45 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
TR50 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR52 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
TR53 2001-000855 R-CARBON;560ohm,5%,1/4W,AA,TP,2.4x6.4mm
TSR1 2103-000290 VR-SEMI;20KOHM,30%,1/10W,TOP
TSR2 2103-000492 VR-SEMI;5KOHM,30%,1/10W,TOP
TZD1 0403-000562 DIODE-ZENER;MTZ7.5B,7.5V,7.07-7.45V,500m
TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO
VC1L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
VC1R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AH90-10739N ASSY-POWER PCB;MAX870,SEM S.N.A
AH93-10005G ASSY-POWER,MANU;MAX870,POWER MANU SEM
S.N.A
PC1 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
PC2 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
PJ1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRA
PL1 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,
PL2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,
PW1 3711-003112 CONNECTOR-HEADER;BOX,8P,1R,2.5MM,STRAIGH
RF2 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS,5X20
RF3 3601-000282 FUSE-FERRULE;250V,4A,TIME LAG,GLASS,5X20
FUSE1 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
RCW1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRA
RCW3 3708-001044 CONNECTOR-FPC/FC/PIC;5P,1.5MM,STRAIGHT,S
RF4 3601-000282 FUSE-FERRULE;250V,4A,TIME LAG,GLASS,5X20
FUSE1 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
RCW1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRA
RCW3 3708-001044 CONNECTOR-FPC/FC/PIC;5P,1.5MM,STRAIGHT,S
AH93-30005P ASSY-POWER,TAPG;MAX870,POWER,AUTO SEM
S.N.A
RF1 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
RF2 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
RF3 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
RF4 3602-000147 FUSE-CLIP;250V,7.5A,30mohm
AH90-10740X ASSY-FRONT PCB;MAX850,SPA
AH93-10003H ASSY-FRONT,MANU;MAX850,FRONT MANU SPA
EVR1 3406-001022 SWITCH-ROTARY;5V,0.5MA,24PULSE/NO CLICK,
FCW2 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT
FCW2 3809-001034 CABLE-FLAT;30V,80C,170MM,22P,1.25MM,UL28
FCW3 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT,
FCW3-1 3708-000307 CONNECTOR-FPC/FC/PIC;7P,1.25MM,ANGLE,SN
FCW3-1 3809-001092 CABLE-FLAT;30V,80C,300mm,7P,1.25mm,UL289
FWC1 3710-001271 CONNECTOR-SOCKET;32P,1R,1.25mm,STRAIGHT-
MJOG1 3406-001023 SWITCH-ROTARY;5V,0.5MA,24DETENT/CLICK,12
R-EYE AH59-60001J MODULE-REMOCON;GP1U271R,38KHZ,-,MESH,-,
UIC3 1204-000156 IC-EQUALIZER;BA3834S,DIP,18P,-,PLASTIC,7
UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7
UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5
VFD AH07-20045S VF-DISPLAY;SVA-16MM14,16SEG,125.0X40.0,M
VFD AH61-20483A HOLDER-VFD;-,ABS,94HB,BLK,-,MAX870
AH93-20003E ASSY-FRONT,CHIP;MAX850,FRONT CHIP SPA
UC101 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
UC17 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,
UC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,
UC24 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,
UC48 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,
UC51 2203-001619 C-CERAMIC,CHIP;27pF,5%,50V,NPO,TP,2012,2
UC52 2203-001619 C-CERAMIC,CHIP;27pF,5%,50V,NPO,TP,2012,2
UC53 2203-001105 C-CERAMIC,CHIP;6.8NF,10%,50V,X7R,TP,2012
UC54 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
UC55 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
UC57 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
UC58 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
UIC1 AH09-10062Y IC-MCU;LC866548V-XXXX,100P,QFP,MAX850
UIC2 AH14-10004L IC;NJU3718,SOP,BULK
UIC5 0801-000305 IC-CMOS LOGIC;7SU04,INVERTER,SOP,5P,150M
UIC5 0801-000305 IC-CMOS LOGIC;7SU04,INVERTER,SOP,5P,150M
UR1 2007-000565 R-CHIP;220Kohm,5%,1/10W,DA,TP,2012
UR105 2007-000401 R-CHIP;150ohm,5%,1/10W,DA,TP,2012
UR111 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR112 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR113 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR114 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR120 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
UR130 2007-000872 R-CHIP;4.7Kohm,5%,1/10W,DA,TP,2012
UR135 2007-001201 R-CHIP;820ohm,5%,1/10W,DA,TP,2012
UR136 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR137 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR137 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR138 2007-000241 R-CHIP;1.5Kohm,5%,1/10W,DA,TP,2012
UR142 2007-001201 R-CHIP;820ohm,5%,1/10W,DA,TP,2012
UR143 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR144 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR145 2007-000241 R-CHIP;1.5Kohm,5%,1/10W,DA,TP,2012
UR146 2007-000267 R-CHIP;1.8Kohm,5%,1/10W,DA,TP,2012
UR147 2007-000518 R-CHIP;2.7Kohm,5%,1/10W,DA,TP,2012
UR148 2007-000686 R-CHIP;3.3Kohm,5%,1/10W,DA,TP,2012
UR149 2007-000981 R-CHIP;5.6Kohm,5%,1/10W,DA,TP,2012
UR150 2007-001177 R-CHIP;8.2Kohm,5%,1/10W,DA,TP,2012
UR151 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
UR152 2007-000774 R-CHIP;33Kohm,5%,1/10W,DA,TP,2012
UR153 2007-000941 R-CHIP;47Kohm,5%,1/10W,DA,TP,2012
UR154 2007-001201 R-CHIP;820ohm,5%,1/10W,DA,TP,2012
UR155 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR156 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
UR157 2007-000241 R-CHIP;1.5Kohm,5%,1/10W,DA,TP,2012
UR158 2007-000267 R-CHIP;1.8Kohm,5%,1/10W,DA,TP,2012
UR159 2007-000518 R-CHIP;2.7Kohm,5%,1/10W,DA,TP,2012
UR160 2007-000686 R-CHIP;3.3Kohm,5%,1/10W,DA,TP,2012
UR162 2007-001177 R-CHIP;8.2Kohm,5%,1/10W,DA,TP,2012
UR163 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
UR169 2007-000468 R-CHIP;1Kohm,5%,1/10W,DA,TP,2012
UR171 2007-000282 R-CHIP;100Kohm,5%,1/10W,DA,TP,2012
UR172 2007-000586 R-CHIP;22Kohm,5%,1/10W,DA,TP,2012
UR173 2007-000493 R-CHIP;2.2Kohm,5%,1/10W,DA,TP,2012
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 8-5
