Samsung MAX-870 - Page 58

Electrical Parts List
8-18 Samsung Electronics
Location no.
*VFD List
PCB Ass’y
Front PCB
Ass’y
Location no.
VFD
AH07-20045T
O
O
VF-DISPLAY ; SVA-16MM 14,16SEG,
125.0*40.0
Code no.
Description & Specification
Description & Specification
Description & Specification
MAX870
MAX880
*Power Transformer Code List
AH26-80142X
AH26-80142Y
AH26-80142Z
AH26-80142U
AH26-80142V
AH26-80142W
MAX-880
MAX-870/MAX-860
MAX-850
MAX-850
MAX-870/MAX-860
MAX-880
115/230V
115/230V
115/230V
115/230V
115/230V
115/230V
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
TRANS-POWER ; E185,8*57,115/230V, 50/60Hz
Code no.
Model
Power Source
*BAND-Option List (Main PCB Ass’y)
AH40-10001T
AH40-10001U
2707-000029
2707-000586
2707-000300
3811-000389
0501-000398
2903-000102
2903-000105
3811-000389
2903-000105
AH27-80060B
AH26-80060A
TFE1
J6,7,8
TR20,21
TR22
JW3,4
IQ5,6,7
TFL1,3
JW18
TFL2
TL1
X
O
X
O
O
X
O
X
O
O
X
O
X
X
O
O
X
X
O
X
X
O
O
X
X
O
O
X
X
O
O
X
O
O
X
X
O
O
X
TUNER ; FE415-G11,-,75ohm
TUNER ; FE337-A05,-,75ohm
R-CHIP ; 0ohm, 5%,1/10W,DA,TP,2012
R-CHIP ; 22Kohm, 5%,1/10W,DA,TP,2012
R-CHIP ; 10ohm, 5%,1/10W,DA,TP,2012
WIRE-NO SHEATH CU ; SPCW,300V,52.4MM
TR-SMALL SIGNAL ; KSC945,NPN,250mW,
TO-92,T
FILTER-CERAMIC ; BP,10.7MHZ+ -25KHZ
150KHZ +
FILTER-CERAMIC ; BP,10.7MHZ+ -25KHZ
180KHZ +
WIRE-NO SHEATH CU ; SPCW,300V,52.4MM
FILTER-CERAMIC ; BP,10.7MHZ+ -25KHZ
180KHZ +
COIL-OSC ; RBQ-07VB,373UH,MW/LW-RF
COIL-OSC ; RBW-07VB,345UH,AM+RF
Code no.
T-BAND
L-BAND
(General)
L-BAND
(FTZ,CE)
