Samsung MAX-888

Samsung Electronics
7-7
Exploded Views and Parts List
7-4 CD Deck Exploded View and Parts List (Option)
No. Code No. Description Specification Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
AH59-20004Y
AH61-10022B
AH63-30048A
AH66-20016A
AH66-20017A
AH66-20018A
AH71-50036A
15253-503-011
AH64-10648A
AH66-90029A
AJ30-20001B
AH61-60055A
AH31-10009A
AH31-10002B
AH60-10014A
DECK-CD
CHASSIS-DECK(M)
COVER-GEAR
GEAR(A)
GEAR(B)
GEAR(C)
SHAFT-PU
CENTER-RING
CENTER-KNOB
TURN-TABLE(M)
PICK-UP CDP
SPRING-T/TABLE
MOTOR-SPINDLE
MOTOR-FEED
SCREW-PH(+M2*3)
CMS-P30AM6UD
CMSP30 POM M90-44
CMS-V30 BLK ABS
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z16/Z90 SP POM
CMS-V30 D3 L79 SUS 420J2
ABS+GS 20% CMS-V10N
ABS 94HB
-,-,-,CMS-V30
P/U SOH-A1 ROW V-P/J
CS STS-W PI0.4 D5.7 L9.3 CMS-V10N
RF-310T-11400 43L 25V 85mA
RF-310TA 30MM NDM4RA3ETL 11.0MM
+M2X3 FE FZY W700
