2-1-3 Application Model : MAX909/910/916 - Samsung Cassette Deck(Auto Stop)
2
3
4
5
6
3
4
7
1
1
6
7
No. Code No. Description Specification Remarks
AH59-20005K DECK-CASSETTE ADR2006FW2
1 AH81-10025E IDLER ARM ASS’Y ADR02-042
2 AH81-11037Q MOTOR EG530YD2BH
3 AH81-10025J FR ARM ASS’Y ADR22-012
4 AH81-11150W R/P HEAD TC-591
5 AH81-11150X ERASE HEAD TC-230AN
6 AH81-10026L BELT MAIN 59.7 PI X 1.0T
7 AH81-10026H BELT SUB 34.7 PI X 1.0T
Samsung Electronics 2-3
