5-8 Samsung Electronics
Exploded View & Part List
Loc. No. Part No. Description;Specification Q’ty SNA Remark Loc. No. Part No. Description;Specification Q’ty SNA Remark
This Document can not be used without Samsung’s authorization.
1204-003018 IC-VOLUME/TONE CONT.;LC75106V,SSOP, 1 SNA
2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4 3 SNA
2003-000468 R-METAL OXIDE(S);10ohm,5%,1W,AA,TP, 1 SNA
2007-000940 R-CHIP;47Kohm,1%,1/4W,TP,3216 1 SNA
2201-000128 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,BK 1 SNA
2201-000879 C-CERAMIC,DISC;2.2NF,10%,1KV,Y5P,BK 1 SNA
2201-002213 C-CERAMIC,DISC;0.47nF,10%,400V,Y5P, 1 SNA
3601-001496 FUSE-RADIAL LEAD;250V,5A,TIME DELAY 1 SNA
AH26-00357A TRANS SWITCHING;E1312,HT-Z320,12V,P 1 SA
AH26-00362A TRANS SWITCHING;EER-3541,MAX-DG56,1 1 SNA
AH27-00069A COIL FILTER;8019P-02-220L,22uH,0.1o 2 SA
AH29-00012A FILTER LINE NOISE;HXD7JUA,0.2,6.0mH 1 SNA
AH29-00016B FILTER LINE;HT-Z320,TR16 4.0mH,0.08 1 SA
AH61-02945A HOLDER-SCREW;MAX-G55,ABS,7,4,BLACK, 1 SNA
AH63-01844A EARTH;HT-Z320,C2680R-1/2H,0.5,NO 1 SNA
AH99-00446A ASSY AUTO INSERT;MAIN PCB ASSY,MAX- 1 SNA
M0045 AH98-00185F ASSY ACCESSORY;MAX-G55/G56,XAP,-,- 1 SNA
6801-001763 CARD-REGISTRATION;Europe Registrati 1 SNA
PE I/B 6902-000385 BAG PE;LDPE,T0.03,W250,L350,TRP,8,1 1 SNA
M0025 AH42-00021A ANT FM T;T18011F-1,75 ohm,1800mm 1 SA
AH68-00650L MARK RECYCLE-CARD-WARRANTY;YP-P2,EL 1 SNA
T0511 AH68-02162F MANUAL USERS;MAX-G55/G56,EDC,ENG/FR 1 SNA
T0511 AH68-02162G MANUAL USERS;MAX-G55/G56,EDC,POL/HU 1 SNA
T0511 AH68-02162H MANUAL USERS;MAX-G55/G56,EDC,GRE/RU 1 SNA
AH68-50254B LABEL-SERIAL;T0.1,L10,W45,SME/SEHZ 2 SNA
T0685 4301-000116 BATTERY-ALKALINE;1.5V,R03,10.5x44.5 2 SA
AH98-00188J ASSY LABEL;MAX-G55,-,-,- 1 SNA
C0104 3809-001221 CABLE-FLAT;30V,80C,210mm,30P,1.25mm 1 SA
PE-BAG 6902-000068 BAG PE;HDPE/NITRON/HDPE,T0.02/0.5/0 1 SNA
CW001 AH65-30010A CLAMP-WIRE;-,-,-,-,-,- 1 SNA
L-BARC AH68-00371A LABEL-BAR CODE;DVD-611/XAA,MOJO2000 2 SNA
CCM1 AH68-01929H LABEL RATING;HT-A100,ELS,SLIVER PET 2 SNA
AH68-02192C LABEL-POP;MAX-G55,EUR,RAINBOW,0.18, 1 SNA
AH69-02436A CUSHION-L;MAX-G55,EPS,-,85,442,264, 1 SNA
AH69-02438A CUSHION-R;MAX-G55,EPS,-,85,442,264, 1 SNA
AH68-02229E LABEL-POP;MAX-G56,ALL,ART PAPER,0.1 1 SNA
P005 AH94-02245C ASSY PCB FRONT;FRONT PCB ASSY,MAX-G 1 SNA
A0701 AH07-00249A VF DISPLAY;HNV-10MS31T,MAX-DG55,80. 1 SA
AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,160 2 SNA
AAR35 2001-000241 R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x 2 SNA
AC510 3708-001577 CONNECTOR-FPC/FFC/PIC;30P,1.25mm,ST 1 SA
AC611 2203-005194 C-CER,CHIP;0.22nF,10%,50V,X7R,1608 6 SNA
AH410 AH61-02727A HOLDER-VFD;HIPS,MAX-G55,41,82 1 SNA
AHR54 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x 2 SA
AL1 2703-000275 INDUCTOR-SMD;33UH,10%,2012 2 SA
AS170 AH63-01861B SHEET-VFD;MAX-G55,PC,0.5,32.5,79,ma 1 SNA
C 2401-000042 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 2 SA
C 2401-000970 C-AL;22uF,20%,50V,WT,TP,5x11,5 1 SNA
C212 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 4 SNA
C610 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,5 4 SNA
C661 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50 1 SNA
CER04 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SNA
D0254 0609-001352 MODULE REMOCON;HORIZONTAL,20mm,TR 1 SNA
EMC10 2401-000487 C-AL;10uF,20%,50V,GP,TP,6.3x5mm,5 4 SNA
FAC11 2401-000651 C-AL;2.2uF,20%,50V,GP,TP,4x7,5 2 SA
FAN1 3711-000820 HEADER-BOARD TO CABLE;BOX,2P,1R,2.5 1 SA
FU1 1003-002129 IC-VFD;PT6315A,LQFP,44P,10x10mm,-40 1 SA
HJ1 3722-001588 JACK-PHONE;7P,AG,BLK,STRAIGHT 2 SA
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012 1 SNA
JP19 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 1 SNA
JP21 3811-001868 WIRE-NO SHEATH CU;SnCuFe,52mm,GRY 27 SNA
KAR21 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 2 SNA
KD2 0401-000005 DIODE-SWITCHING;1N4148,75V,150mA,DO 8 SA
KR7 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 8 SNA
KSW5 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6x5,SP 14 SNA
L0405 0601-001754 LED;SMD,BLUE,1.6X0.8X0.4MM,468NM,1. 16 SNA
L0405 0601-002762 LED;SMD(TOP VIEW),RED,1.6x0.8mm,632 16 SNA
MR312 2007-000450 R-CHIP;180ohm,5%,1/10W,TP,1608 16 SNA
PQ44 0501-002409 TR-SMALL SIGNAL;KTC945B,NPN,625mW,T 4 SA
PZD05 0403-001321 DIODE-ZENER;MTZJ6.8C,6.7-6.97V,500m 1 SA
PZD22 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57/9.01V,500 1 SNA
R109 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 4 SNA
R17 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x 1 SNA
R1P10B 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3 8 SA
R1P110 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x 5 SNA
R1P124 2001-000660 R-CARBON;33Kohm,5%,1/8W,AA,TP,1.8x3 1 SNA
R3A04 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x 2 SNA
R40 2001-001000 R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3 1 SNA
R4N03 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3 4 SNA
R660 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3 4 SA
R668 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3 1 SNA
SCR2 2001-000995 R-CARBON;820ohm,5%,1/8W,AA,TP,1.8x3 2 SA
SCR3 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3. 4 SNA
T0076 AH39-01045A WIRE HARNESS;MAX-DG56,2pin,#1 Black 1 SNA
UC2C 2203-000062 C-CER,CHIP;47nF,+80-20%,50V,Y5V,160 2 SNA
UVR1 3406-001047 SWITCH-ROTARY;5V DC,0.5mA,12mm 1 SA
VL9 3301-001419 BEAD-SMD;220ohm,1608,TP,133ohm/70MH 2 SA
ZPE1 2401-001952 C-AL;4.7uF,20%,50V,GP,TP,5x7mm,5mm 1 SA
0403-000344 DIODE-ZENER;UZ3.9B,3.7-4.1V,500MW,D 1 SA
2003-000554 R-METAL OXIDE(S);2.2ohm,5%,1W,AA,TP 1 SA
AH41-01215A PCB-FRONT;MAX-DG55,KH,1,0,T1.6,168* 1 SNA
AH97-03572A ASSY AUTO-FRONT;MAX-G56R/EUR,AH94-0 1 SNA
AH97-03574A ASSY MANUAL INSERT;FRONT PCB ASSY,A 1 SNA
T0268 AC39-10019A CBF-POWER CORD;KKP-419C,H03VVH2-F,V 1 SA
AH69-02454B MASTER CARTON;MAX-G55,PAPER,7,W683, 2 SNA
A001 AH59-02147A REMOCON-ASSY;MAX-G55-EUR,SAMSUNG,17 1 SNA
To Next Page
