Process
4. MCU
address and
port setting
for indoor
unit
(for wired
remote
controller)
– Setting for MWR-WG0**
1) Press the
and buttons at the same time for more than 3 seconds. Then you can enter the
password(0202) and press the OK button.
2) Assign an indoor unit MCU port address with [Major] General Ꮡ [Step1] Indoor unit/
Ventilator option Ꮡ [Step2] MCU port Ꮡ [Step3] MCU address & MCU port.
J For more information, please refer to the installation manual of MWR-WG0**
Major Step1 Step2 Step3 Description
General
Indoor unit/
Ventilator option
MCU port
MCU address 00 to 15
MCU port A to F
0
Please enter your PASSWORD
Service mode
3. Setting by using S-NET Pro 2
Set the pipe addresses by using Add-on > Change address on S-NET Pro 2. (For more information, see
the S-NET Pro 2 Help.)
ki]_TW]`WZhTW\pttj|GrniluRmyUGGGY^ YWYYTXXTYYGGG㝘㤸G_a\`aWX
