Samsung MH026FNCA User Manual

Exploded Views and Parts List
5-10Samsung Electronics
■
Parts List
No. Code No. Specification
Q'TY
SA/SNA
Description
1 DB61-03127A BRACKET-PAN SGCC-M,1.0,12,20, 2 SNA
2 DB64-01763B CABINET-IN ABS,T2.5,W360,L1010,NTR 1 SNA
3 DB64-01764A CABINET-CUSHION EPS,-,310,835,-,WHT 1 SNA
4 DB61-03836A PLATE-HANGER SGCC-M,1.2 4 SA
5 DB94-00258A ASS'Y BEARING G-PJT,CR,BLK 1 SA
5-1 DB73-00128A RUBBER-BEARING G-P/J,CR,55,BLK 1 SNA
5-2 DB94-40007A ASS'Y BEARING ASS'Y,POLYSLIDER-PG5 1 SA
6 DB94-01546A ASS'Y-DRAIN SOCKET ASS'Y 1 SNA
6-1 DB62-04236A VALVE CHECK ASS'Y,72.5 1 SA
7 DB70-00754A PLATE-COVER CONTROL SGCC-M,0.7,96,428 1 SNA
8 DB93-07192C ASS'Y PCB MAIN FR-4,1.6T,230mmx70mm,SMPS 1 SA
9 DB61-03126B CASE-CONTROL ABS(5V),T2.5,W429.8,L47,NTR 1 SNA
10 DB70-00755A PLATE-CASE CONTROL SGCC-M,0.7,96,428 1 SNA
11 DB73-00307B RUBBER-WIRE HOLE CR V0 1 SNA
12 DB95-01058D ASS'Y-TERMINAL BLOCK 2P 1 SNA
13 DB95-01101E ASS'Y-TERMINAL BLOCK 4P,F1,F2,V1,V2 1 SNA
14 DB31-00561A MOTOR FAN Y4S476A59,0.2A,42W,220V/230V,1250,50/60Hz 1 SA
15 DB63-01698A COVER MOTOR ABS,2.5,147,135,GRAY 1 SNA
16 DB94-00040Y ASS'Y-CROSS FAN ASS'Y 1 SA
17 DB67-00833A DRAIN-PUMP PBT,1.0,WHITE 1 SA
18 DB69-00137A BAND-RING STS304,T1.5,PI14 1 SNA
19 DB73-00390B RUBBER-BASE PUMP NBR,30,BLK 1 SNA
20 DB73-00391D RUBBER-CAP PUMP EPDM,40 1 SNA
21 DB63-01699A COVER-PUMP ABS,2.5,78,100,GRAY 1 SNA
22 DB95-01359F ASS'Y-SENSOR FLOAT SLIM1WAY SmH250-02L,180mm,RED,BLK 1 SA
23 DB94-01367E ASS'Y DRAIN PAN ASS'Y 1 SA
24 DB73-00133B RUBBER-CAP DRAIN SOCKET NBR,38.30.27.24/15.12.9.4,45,15,BLK 1 SNA
25 DB94-01492A ASS'Y DRAIN PAN-SUB ASS'Y 1 SA
26 DB96-08129C ASS'Y EVAP TOTAL ASS'Y 1 SA
26-1 DB60-30010A NUT-FLARE HEX,7/16-20UnF 1 SA
26-2 DB60-30010B NUT-FLARE HEX,3/4-16UnF 1 SA
27 DB94-01904B ASS'Y DRAIN-HOSE INSTALL ASS'Y 1 SA
27-1 DB62-05810A SEAL-DRAIN ASS'Y ASS'Y 1 SNA
27-2 DB62-04783A INSULATION DRAIN-HOSE FOAM-PE,T12,20,165,GREY,NON FLAmmABILITY 1 SNA
27-3 DB63-00237A GROMMET-HANGER NBR 8 SNA
27-4 DB67-00285A DRAIN HOSE-SOCKET POM,T3 1 SNA
27-5 DB72-00401C INSULATION JOINT-OUT FOAM-PE,T3,W200,L200,GREY 2 SNA
27-6 DB94-01258C ASS'Y DRAIN-HOSE JOINT ASS'Y 1 SA
27-6-1 DB67-00923A DRAIN HOSE-HOUSING ABS(GP35),GREEN 2 SNA
27-6-2 DB67-00336E HOSE DRAIN-PVC SOFT PVC,14,20,3,GRAY 1 SNA
27-6-3 DB67-00805B DRAIN HOSE-JOINT B ABS,T3.0,NORmAL 1 SA
