Samsung MH026FNCA User Manual

Exploded Views and Parts List
5-12Samsung Electronics
■
Parts List
No. Code No. Specification
Q'TY
SA/SNA
Description
1 DB31-00370A MOTOR STEP
35BYJ46,DC12V800gf.cm,SmH250-05L(WHT),100mm 1 SA
2 DB61-02894A HOLDER-PUSH LATCH POM,PC+PE,11.9,12.9,21,BLACK 3 SA
3 DB61-03123A GUIDE-AIR OUTLET HIPS,2.5,70,860,GRAY 1 SNA
4 DB61-03124A GUIDE-CUSHION AIR OUT LF EPS,105,426,WHT 1 SNA
5 DB61-03125A GUIDE-CUSHION AIR OUT RH EPS,105,463,WHT 1 SNA
6 DB63-01694A FILTER-AIR INLET ABS,2,196,437,BLK 1 SA
7 DB63-01695A FILTER-AIR INLET G ABS,2,196,320,BLK 1 SA
8 DB63-01697A COVER-DISPLAY PCB HIPS,2.5,117,154,BLK 1 SNA
9 DB64-00237A PANEL-DISPLAY LED AKM-2800,PC 1 SA
10 DB64-01759A PANEL FRONT-SLIM 1WAY ABS,40,465,1180,DA White 1 SNA
11 DB64-01760A WINDOW-DISPLAY PCB PC,1.5,40,40,-,MILKY WHT 1 SNA
12 DB64-01762A GRILLE-AIR INLET ABS,2.0,213,859,WHT 1 SA
13 DB65-00023A CLIP-WIRE-ASS'Y NYLON,AG-240E 1 SNA
14 DB66-01187A BLADE-G ABS,5,11.6,WHT 1 SNA
15 DB93-05321A ASS'Y PCB SUB FR-1,LEAD FREE 1 SNA
16 DB63-01696A COVER-SCREW ABS,2.5,19,34,WHT 1 SNA
