Samsung MH026FNCA User Manual

Exploded Views and Parts List
5-18Samsung Electronics
■
Parts List
Q'TY
SA/SNANo. Code No. Description Specification
1 DB90-01146G ASS'Y CABINET FRONT ASS'Y 1 SA
1-1 DB63-00838B GUARD FAN PP,SC-90073R 1 SA
2 DB90-03278B ASS'Y BASE OUT ASS'Y 1 SNA
3 DB67-00142A FAN PROPELLER PP 1 SA
4 DB31-00492A MOTOR FAN SGCC-M 1 SA
5 DB61-00686A BRACKET MOTOR ASS'Y 1 SA
6 DB94-01326A ASS'Y PARTITION ASS'Y 1 SNA
7 DB96-09225A ASS'Y CONDENSER ASS'Y 1 SA
8 DB64-02083B SCREEN-COND BAR HSWR(SC-90073T) 1 SA
9 DB90-03096B ASS'Y CABINET SIDE ASS'Y 1 SA
10 DB90-03305A ASS'Y COVER CONTROL ASS'Y 1 SA
11 DB90-03275A ASS'Y CABINET UP ASS'Y 1 SA
12 DB90-01351A ASS'Y CABINET LF SECC-P 1 SA
13 G8T200FUAEW ROTARY COMPRESSOR BLDC PERMANENT MAGNETIC MOTOR 1 SA
13-1 DB63-00763A GROMMET-ISOLATOR NR 3 SNA
14 DB96-08909A ASS'Y VALVE 4-WAY ASS'Y 1 SA
15 DB96-08910B ASS'Y VALVE ASS'Y 1 SA
16 DB93-05697C ASS'Y CONTROL OUT ASS'Y 1 SA
16-1 DB93-05700C ASS'Y PCB MAIN ASS'Y 1 SA
16-2 DB61-02974B CASE CONTROL-COVER ASS'Y 1 SA
16-3 DB62-05315A HEAT SINK ABS 1 SNA
16-4 DB93-04745B ASS'Y PCB EMI ASS'Y 1 SNA
16-5 DB61-02973B CASE CONTROL-BASE AL 1 SA
16-6 DB70-00730A PLATE-CONTROL OUT UPPER ABS 1 SNA
16-7 DB70-00928A PLATE-CONTROL OUT MAIN SGCC-M 1 SNA
16-8 DB65-00181D TERMINAL BLOCK BLK 1 SC
16-9 DB65-00181F TERMINAL BLOCK BLK 1 SC
16-10 DB95-01180A ASS'Y-TERMINAL BLOCK ASS'Y 1 SC
16-11 DB93-06290A ASS'Y PCB DISPLAY ASS'Y 1 SA
17 DB27-00042A REACTOR 5MH±5%,40.0±5V 1 SA
18 DB32-00175B THERMISTOR CONDENSER 103AT,204CTB 1 SA
19 DB32-00176A THERMISTOR 103AT,204CTB 1 SA
