Samsung MH026FNCA User Manual

Exploded Views and Parts List
5-20Samsung Electronics
■
Parts List
Q'TY
SA/SNANo. Code No. Description Specification
1 DB90-03918A ASS’Y CABI FRONT-TOTAL ASS’Y 1 SNA
1-1 DB63-00831B GUARD FAN-P PP,SC-90073R 1 SA
2 DB90-03278C ASS’Y BASE OUT-TOTAL ASS’Y 1 SNA
3 DB67-00861A FAN PROFELLER AS-GF 20% 1 SNA
4 DB31-00512A MOTOR FAN 65A,130W,DC 310V 1 SA
5 DB61-20094D BASE MOTOR SGCC-M 1 SNA
6 DB94-01824A ASS’Y PARTITION ASS’Y 1 SNA
7 DB96-09223A ASS’Y COND ASS’Y 1 SNA
8 DB71-00122B BAR STEEL HSWR 1 SNA
9 DB90-03920A ASS’Y CABINET-SIDE RH ASS’Y 1 SNA
10 DB90-03919A ASS’Y CABI BACK-RH ABS 1 SNA
11 DB90-03275A ASS’Y CABINET UP ASS’Y 1 SNA
12 DB90-03932A ASS’Y CABINET-SIDE LF PAINT ASS’Y 1 SNA
13 G8T260FUAEW COMPRESSOR BLDC INVERTER 1 SA
13-1 DB63-00763A GROMMET ISOLATOR NR 3 SNA
14 DB96-09230A ASS’Y 4WAY VALVE ASS’Y 1 SNA
15 DB96-09236B ASS’Y VALVE ASS’Y 1 SNA
16 DB93-05697A ASS’Y CONTROL OUT ASS’Y1SA
16-1 DB93-05700A ASS’Y PCB MAIN ASS’Y1SA
16-2 DB61-02974B CASE CONTROL COVER ABS 1 SA
16-3 DB62-05315A HEAT SINK 1 SNA
16-4 DB93-04745C ASS’Y PCB SUB EMI ASS’Y 1 SNA
16-5 DB61-02973B CASE CONTROL BASE ABS 1 SNA
16-6 DB70-00910A PLATE-CONTROL OUT SGCC-M 1 SC
16-7 DB65-00181D TERMINAL BLOCK BLK 1 SC
16-8 DB65-00181F TERMINAL BLOCK BLK 1 SC
16-9 DB95-01180A ASS’Y-TERMINAL BLOCK ASS’Y1SC
16-10 DB93-06290A ASS’Y PCB SUB-DISPLAY ASS’Y1SA
17 DB27-00043A REACTOR 20A, 50Hz 1 SA
18 DB32-00175B THERMISTOR COND 103AT,204CTB 1 SC
19 DB32-00176C THERMISTOR WIRE OUT/DISCHARGE 103AT,204CTB 1 SC
20 DB90-04157A ASS’Y HANDLE ASS’Y1SA
