Samsung Electronics8-11
PCB Diagram
!
Power N
@
Power L
#
BLDC FAN
$
AC FAN
%
Communication 485
^
COND/OLP Temperature Sensor
&
DIS/OUT Temperature Sensor
*
EEV Connector
(
Comp. Connector Wire
)
Reactor Connector Wire
■ MH050FXEA2B/MH060FXEA3B/MH070FXEA4B/MH080FXEA4B
The red number connecter is not used.
#
$
