Samsung MM-39 - Page 5

JC22 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC23 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC7L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC7R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC3 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC4 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC23 2401-001936 C-AL;22UF,20%,16V,GP,TP,5X11MM,5MM
TC24 2401-001936 C-AL;22UF,20%,16V,GP,TP,5X11MM,5MM
AC29 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
JC18 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
JC70 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
QC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
QC9L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
QC9R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC11 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC5 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC6 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
JC55 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC44 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
AC7 2401-001969 C-AL;470UF,20%,25V,GP,TP,10X12MM,5M
AC40 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
AC41 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC11L 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC11R 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC31 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC33 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC3L 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC3R 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC58 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
MC9 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC21 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC33 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC35 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC56 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC71 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
MC3 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC1L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC1R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC2L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC2R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC3L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC3R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC4L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC4R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC5L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
QC5R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
HL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
HL2 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
DFT1 2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL
DBEAD1 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
DBEAD2 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
MBEAD1 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
AIC3 AC14-12001G IC;KA78L05,T,-
TVD1 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
AQ1 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN,BK,1
EIC1 1201-000163 IC-OP AMP;BA4560F-E2
JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PLASTIC
AIC1 1201-001454 IC-POWER AMP;7499,ZIP,11P,-,-,-,PLASTIC,18V,23W,0TO+7
AQ2 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,-,PLASTIC,11.5/
AR44 2003-000556 R-METAL OXIDE(S);2.2ohm,5%,2W,AA,TP,4x12mm
AC15 2401-001883 C-AL;1000UF,20%,25V,GP,BK,16X25MM,5
AC16 2401-001883 C-AL;1000UF,20%,25V,GP,BK,16X25MM,5
AC20 2401-003116 C-AL;4700uF,20%,35V,-,BK,18X35.5,7.
TX2 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM
MX1 2801-003601 CRYSTAL-UNIT;4.332MHz,30ppm,28-AAM,30pF,
TCF3 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
TCF4 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
DOUT 3707-001005 CONNECTER-OPTICAL;PLUG,SM,-,4.4/2.OMM
MJ3 3711-000814 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,ANGLE,SN
DWF1 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
JCW1 3711-001062 CONNECTOR-HEADER;BOX,6P,1R,2mm,STRAIGHT,SN
SCW1 3711-001234 CONNECTOR-HEADER;NOWALL,11P,1R,2.0mm,ANGLE,SN
SCW2 3711-001234 CONNECTOR-HEADER;NOWALL,11P,1R,2.0mm,ANGLE,SN
MJ4 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A
MJ5 3716-000210 TERMINAL-BLOCK;-,-,-,60V,7A
EJ1 3722-000355 JACK-PHONE;3P,3.5MM,AG,BLK,-
MJ2 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22
HJ1 3722-000495 JACK-PHONE;11P,3.5MM,-,AG
JIC2 AH14-10002H IC;LA2010,-,
MIC7 AH14-10007G IC;LC72131,DIP,STICK PLL
MIC6 AH14-10008B IC;LA1837,DIP,RF+MPX
TFT1 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BULK,
JT1 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,-,-,850PF,105KHZ
TFT2 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
TL6 AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC
TL11 AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC
TL9 AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT
TL10 AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT
AL1 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL2 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL3 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
DWE1 AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28
JCW1-1 AH39-00064A LEAD CONNECTOR-ASSY;-,51004,-,6P,150MM,1007#28
JCW3 AH39-00065A LEAD CONNECTOR-ASSY;-,5264,2.5,-,5P,150MM,1007#28
MWF5 AH39-20002S LEAD-CONNECTOR ASS’Y;5264,-,4P,200MM,1533#28
JCW2 AH39-20022G LEAD-CONNECTOR ASS’Y;51004,5295,8P,300MM,1007#28
ECW1 AH39-20560R LEAD CONNECTOR-ASSY;-,5264,35022,3P,200m
DECK AH39-50001K LEAD-FASTEN;RING,1007#24,140MM,BLK
SHASS AH39-50001K LEAD-FASTEN;RING,1007#24,140MM,BLK
TFE1 AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm
DRW1R AH61-40022A STUD-TAP;SPC1,T0.5,BT2,-,-,
EIC1 1201-000163 IC-OP AMP;BA4560F-E2
MIC5 1201-000163 IC-OP AMP;BA4560F-E2
MIC8 1201-000163 IC-OP AMP;BA4560F-E2
MIC4 1204-001465 IC-VOLUME/TONE CONT.;TDA7440D,SOP,28,18.
TR25 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
AR55 2007-000032 R-CHIP;390KOHM,5%,1/10W,DA,TP,2012
JR57 2007-000032 R-CHIP;390KOHM,5%,1/10W,DA,TP,2012
JR19 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
QR4R 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
JR28 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
TC18 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
TC19 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
JR61 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR4 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
JR63 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
MR3 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR001 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR28 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR6 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
AR61 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR62 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR30 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR61 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
QR9L 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
QR9R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR1 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR56 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR70 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR71 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR55 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000401 R-CHIP;150OHM,5%,1/10W,DA,TP,2012
JR17L 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
JR17R 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR14 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
JR3L 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
JR3R 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
AR31 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR12L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR12R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
QR5L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
QR5R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR16 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR47 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
CR2 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR60 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR66 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR7L 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR7R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR38 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR44 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR13 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
AR70 2007-000565 R-CHIP;220KOHM,5%,1/10W,DA,TP,2012
QR7L 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
QR7R 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR18 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR19 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR48 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
AR6 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR10L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR25 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR32 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR34 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR26 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR6L 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
JR6R 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
TR2 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
CR7 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
CR8 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
JR9L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
JR9R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
QR6L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
QR6R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR5 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR3 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
QR10L 2007-000778 R-CHIP;330Kohm,5%,1/10W,DA,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-3
