NC110 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,2012,-,TP
NC118 2203-000787 C-CERAMIC,CHIP;330pF,5%,50V,NPO,TP,2012,-
NC101 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC111 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC125 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC100 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC106 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC124 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC204 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
NC2000 2203-001026 C-CERAMIC,CHIP;4pF,0.25pF,50V,SL,TP,2012,-
NC115 2203-001137 C-CERAMIC,CHIP;68nF,+80-20%,50V,Y5V,TP,2012,-
NC190 2203-001256 C-CERAMIC,CHIP;8pF,0.25pF,50V,NPO,TP,2012,2.0
NC104 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC300 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52L 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52R 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC603 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC903 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC102 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC201 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC202 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NC203 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NC50L 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
NC50R 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
NL301 2703-000001 INDUCTOR-SMD;10uH,10%,2.5x3.2x2mm
NL303 2703-000001 INDUCTOR-SMD;10uH,10%,2.5x3.2x2mm
NL300 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
NL302 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
NJW106 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5MM,-,-
NQ1501 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
- 2008-000141 R-FUSIBLE;2.2ohm,5%,1/4W,AA,TP,2.6x6.7mm
NR555 2008-000141 R-FUSIBLE;2.2ohm,5%,1/4W,AA,TP,2.6x6.7mm
NC117 2301-000389 C-FILM,PEF;150nF,5%,50V,TP,12.5x15x7.5,7m
NC105 2401-000243 C-AL;100uF,20%,10V,GP,TP,6.3x5,5
NC501 2401-000243 C-AL;100uF,20%,10V,GP,TP,6.3x5,5
NC702 2401-000243 C-AL;100uF,20%,10V,GP,TP,6.3x5,5
NC704 2401-000243 C-AL;100uF,20%,10V,GP,TP,6.3x5,5
NC902 2401-000243 C-AL;100uF,20%,10V,GP,TP,6.3x5,5
NC114 2401-000407 C-AL;10UF,20%,16V,GP,TP,3.5X5,-
NC700 2401-000868 C-AL;220uF,20%,4V,GP,TP,6.3x5,2.5mm
NC701 2401-000868 C-AL;220uF,20%,4V,GP,TP,6.3x5,2.5mm
NC703 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
NC122 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
NC55L 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
NC55R 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
NC903 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
NJW108 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NIC05 AC14-12001G IC;KA78L05,T,-
AJ59-20003E DECK-CDP;CMS-P30AM6,-,-,-,
****
MM39 Parts List *****
AM-ANT AH42-20001Q ANT-LOOP;-,KS980214-01,18.5uH,CONNECTOR
AH59-10124T REMOCON—ASSY;-,-,-,22KEY,MM29/39,-
DECK AH59-20006H DECK-CASSETTE;ADR241BTR,MM39,DC12V,LOGIC
AH92-00076A ASSY-PCB-MAIN CHIP;MM-39,MAIN CHIP S.N.A.
EIC1 1201-000163 IC-OP AMP;BA4560F-E2
MIC5 1201-000163 IC-OP AMP;BA4560F-E2
MIC8 1201-000163 IC-OP AMP;BA4560F-E2
MIC4 1204-001465 IC-VOLUME/TONE CONT.;TDA7440D,SOP,28,18.
TR25 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
AR55 2007-000032 R-CHIP;390KOHM,5%,1/10W,DA,TP,2012
JR57 2007-000032 R-CHIP;390KOHM,5%,1/10W,DA,TP,2012
JR19 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
JR24 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
QR4R 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
JR28 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
TC18 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
TC19 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
JR61 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR4 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
JR63 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
MR3 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR001 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR28 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR6 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
AR61 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR62 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR30 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR61 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
QR9L 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
QR9R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR1 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR68 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
JR10L 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR56 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR70 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR71 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR26 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR55 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000401 R-CHIP;150OHM,5%,1/10W,DA,TP,2012
JR17L 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
JR17R 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR14 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
JR3L 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
JR3R 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
JR57 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
TCR18 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
TCR19 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
AR31 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR5R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR12L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR12R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR1L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR1R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
QR5L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
QR5R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR16 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR47 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
AR48 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
CR2 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR60 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR66 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR7L 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR7R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR38 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR44 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR13 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR17 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
AR70 2007-000565 R-CHIP;220KOHM,5%,1/10W,DA,TP,2012
QR7L 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
QR7R 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR18 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR19 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR48 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
AR6 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR10L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR25 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR32 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR34 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR26 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR6L 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
JR6R 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
TR2 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
CR7 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
CR8 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
JR9L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
JR9R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
QR4R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
QR6L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
QR6R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR5 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR3 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TR6 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
QR10L 2007-000778 R-CHIP;330Kohm,5%,1/10W,DA,TP,2012
QR10R 2007-000778 R-CHIP;330Kohm,5%,1/10W,DA,TP,2012
QR12 2007-000778 R-CHIP;330Kohm,5%,1/10W,DA,TP,2012
JR6L 2007-000781 R-CHIP;33OHM,5%,1/10W,DA,TP,2012
JR6R 2007-000781 R-CHIP;33OHM,5%,1/10W,DA,TP,2012
JR8L 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
JR8R 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
TR20 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
TR33 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
AR6 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
AR9 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
JR16R 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
QR1L 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
QR1R 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR37 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR65 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
AR11 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
AR29 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
AR8R 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
JR19 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
QR8L 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
QR8R 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
JR4L 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
JR4R 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
JR30 2007-001074 R-CHIP;6.8OHM,5%,1/10W,DA,TP,2012
JR31 2007-001074 R-CHIP;6.8OHM,5%,1/10W,DA,TP,2012
JR5L 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-5
